Brief Overview
Mobile technology is one of the most significant developments of recent
years, and many innovative organisations are harnessing the benefits to
optimise workflow and cut costs. With its compact size and flexible
methods of interface for PC, PDA, and blackberry devices the MW260BT is
the perfect choice for partnering your systems with.
Product Description
General
Model MW-260
Print Engine Direct Thermal
FunctionsA6 Mobile Printer with USB and Bluetooth interface - 300dpi
Standard Memory NA
Drop Protection NA
Keyboard Power Key(On/Off), Interface switch(Bluetooth/IrDA)
Display
Display Type LED Status Indicator: Blue / Green / Red
LED Charging Indicator: Orange
Printer
Emulation3 command (Brother original command, MPrint ESC/P command, P-touch template printer command)
Print Speed Ave.: 20 sec./page or 7.4 mm/sec.(under our standard environment1)
Printer Resolution 300 x 300dpi
Printer Driver Functions Page size: 5(A6, A4->A6(default), A5->A6, B5->A6 and Letter->A6)
Half-tone: 3 (Dithering, Error diffusion, Binary)
Max Print AreaC-211, C-212(A6) = 97.5mm x 140.6mm
C-251(A6) = 93 X 137 mm (Transfer available area)
Paper Handling
Standard Paper Capacity A6 Thermal x (50 sheets/cassette x 20 cassette)
A6 Carbon copy (2ply) x (30 sheets/cassette x 10 cassette)
Media Size General 105mm x 148mm (A6)
Software
Software Development Kit Pocket PC2002/2003, Windows Mobile 5 / 6, Blackberry, Windows 2000/XP/Vista
Template Transfer to Machine Yes
Connectivity
InterfaceUSB 2.0 Full speed
Bluetooth Ver. 2.1+EDR Class 2 (Serial PortProfile)
IrDA Ver 1.3
Operating System Windows PC: Windows 2000 Professional / XP / Vista
Windows Mobile: WM5 / WM6
Mobile Operating System Software Development Kit for Pocket PC2002/2003,
Windows Mobile 5 / 6, Blackberry, Windows 2000/XP/Vista/Windows7
Networking
Wireless Interface NA
Wireless Security NA
Options
Optional Power Rechargeable lithium-ion battery (BT-200)
AC Adapter Auto switching (100-240V)
Optional Car Mount NA
Optional magnetic card reader NA
Optional Carry Case Yes (PCS-100)
Consumable
ConsumablesC-211: A6 Thermal x (50 sheets/cassette x 20 cassette)
C-212: A6 Thermal (Fade resistant) x (50 sheets/cassette x 20 cassette)
C-251: A6 Carbon copy (2ply) x (30 sheets/cassette x 10 cassette)
Weight and Measures
Size130(W) x 210(D) x 18.5(H)mm
Weight520g (including paper cassette and battery)
Environment
Auto Power Off Power-off (5 minutes), Bluetooth sleep mode (3 minutes)
Humidity Operating Humidity: 20 to 80%
Temperature Operating Temperature: 0 to 40deg C
Others
Warranty 12 Months Return To Base
Carton ContentsMW-260, Quick Setup Guide, CD-ROM (Including users guide,
printer driver), USB cable, C-211 thermal paper (50 sheets), Lithium
ion Rechargeable battery pack (BT-200), AC Adaptor
What's in the box?
MW-260, Quick Setup Guide, CD-ROM (Including users guide, printer
driver), USB cable, C-211 thermal paper (50 sheets), Lithium ion
Rechargeable battery pack (BT-200), AC Adaptor
Product Specifications
Up to Print Speed 20 Sec./page
Up to Resolution 300 x 300 dpi
Direct Thermal Printing
Lithiumlon Rechargeable Battery
Blue, Green & Red LED
USB 2.0 & Bluetooth 2.1
One Year Return to Base Warranty
Brochure for Brother MW-260 A6 Mobile Printer
