Canon iPFTX-2000 24" Large Format Inkjet Printer

Brief Overview

IPFTX2000 24" 5 COLOUR PIGMENT LARGE FORMAT PRINTER

Product Description

PRINT HEAD
PF-06
TECHNOLOGY
FINE (Photolithography Inkjet Nozzle Engineering)
PRINT RESOLUTION (MAX.)
2400 x 1200 dpi
LINE ACCURACY*
±0.1% or Less
MINIMUM LINE WEIGHT**
0.02mm
NUMBER OF NOZZLES
Matte Black: 5,120 Nozzles
Other Colours: 2,560 Nozzles per Colour
DROPLET SIZE
5 Picolitre
NOZZLE PITCH (HEAD RESOLUTION)
1200 dpi x two lines
PRINT HEAD SWATH
1.07"
INK TYPE
Pigment: Matte Black (MBK), Cyan (C), Magenta (M),
Yellow (Y), Black (BK)
INK TANK
Shipped with Printer: PFI-310 (330ml) MBK; PFI-110
(160ml) BK, C, M, Y
Replacement: PFI-110 (160ml), PFI-310 (330ml), or
PFI-710 (700ml)
INK SUPPLY METHOD
Tubing System with Sub-tanks
NOZZLE RECOVERY SYSTEM
Non-firing Nozzle Detection and Compensation
PRINTER CONTROLLER
L-COA PRO
PRINTER RAM
128GB (Virtual), 2GB (Physical)
HARD DRIVE
500GB (Encrypted)
MAILBOXES (USER JOB STORAGE)
One Common Inbox; 29 User Inboxes (Password - protected)
MEDIA FEED
Roll Feed: One Roll, Front Loading, Front Output, Manual
MEDIA WIDTH
Roll Feed: 203.2mm–610mm (8"–24")
Cut Sheet: 203.2mm–610mm (8"–24")
PRINTABLE MARGINS
Roll Feed: All Sides: 3mm, 0mm for borderless
MAXIMUM PRINT LENGTH (SINGLE PAGE)†
Roll Feed: 18 m
Cut Sheet: 1.6 m
BORDERLESS PRINTING WIDTHS
(ROLL MEDIA ONLY)
Recommended:
254mm (10"), 355.6mm (14"), 431.8mm (17"), 609.6 mm (24")
Printable:
203.2mm (8"), 304.8mm (12"), 406.4mm (16"), 504 mm (20")
MEDIA CUTTER
Automatic Horizontal Cutting (Rotary Cutter)
MEDIA THICKNESS
0.07–0.8mm
MEDIA INTERNAL DIAMETER SIZES
2" and 3" (Adapters included)
MAXIMUM ROLL OUTER DIAMETER
170mm
MEDIA OUTPUT
Multiposition Basket (Standard)
PRINTING SOFTWARE UTILITIES
Accounting Manager, Apple AirPrint, Device Management
Console, Direct Print & Share, Free Layout Tool,
imagePROGRAF Printer Driver for Windows®/Mac®,
Media Configuration Tool, PosterArtist Lite for Windows,
Printer Driver Extra Kit for Windows/Mac (Free Print Utility
Layout, Advanced Preview), Optimised Driver for AutoCAD,
Print Plug-in for Microsoft® Word/Excel/PowerPoint® for
Windows, Quick Utility Toolbox
OPERATING SYSTEM
Windows 7 (32/64 bit), Windows 8.1 (32/64 bit),
Windows 10 (32/64 bit), Windows Server 2008 R2,
(32/64 bit), Windows Server 2012 (64 bit),
Windows Server 2012 R2 (64 bit), Windows Server
2016 (64 bit), Macintosh OS X v10.10.5–v10.12x
PRINT LANGUAGE
Printer: SGRaster, HP-GL/2, HP RTL, PDF, JPEG
INTERFACE
Standard (Built-in): USB 2.0 Hi -Speed, 10/100/1000Base-T,
Wireless LAN (IEEE 802.11 b/g /n)■
Direct USB Thumb Drive Printing
ACOUSTIC NOISE
Operation: 50 dB (A) or less
Standby: 35 dB (A) or less
Acoustic Power: 6.8 Bels or less
(measured on ISO7779 standard)
POWER SUPPLY
AC 100–240V (50–60 Hz)
POWER CONSUMPTION
Maximum: 91 W or Less
Standby: 3.6 W or Less
Power Off: 0.3 W or Less
OPERATIONAL ENVIRONMENT
Temperature: 15–30 degrees C
Relative Humidity: 10–80% (No Dew Condensation)
PRINTER DIMENSIONS (W X D X H)
AND WEIGHT
With Basket Opened:
1,110mm x 984mm x 1,168mm
Approx. 91kg
PACKAGE DIMENSIONS (W X D X H)
AND WEIGHT
Printer (main unit with stand and pallet):
1,324mm x 902mm x 1,055mm Approx. 110kg
Stacker: 969mm x 906mm x 291mm Approx. 21kg
Roll Unit: 1,244mm x 562mm x 461mm Approx. 22kg
OPTIONS
Roll Unit: RU-22
Roll Holder: RH2-27(2/3")
Stacker: SS-21
PosterArtist
User-Replaceable Items:
Ink Tank (PFI-110/PFI-310/PFI-710)
Print Head (PF-06)
Maintenance Cartridge (MC-30)
Cutter Blade (CT-07)

What's in the box?

Printer, Roll Unit, 1 x Print Head, 1 x Maintenance Cartridge, 3” Paper Core Attachment, EU & UK Power Cable, 1 Set of Starter Ink Tanks, Set Up Guide, Safety/Standard, Software CD-ROM (OSX/Windows), PosterArtist Lite CD-ROM, EU Biocide Sheet, Eurasian Economic Union Sheet, Important Information Sheet, Quick Guide and Print head Alignment Sheet
