Product Description
Built with Epson’s advanced robotics and printing technologies, this compact, integrated disc publisher has all the features you need to burn and print up to 100 (per batch) high-quality customised CDs, DVDs or BDs unattended and on demand. It is ideal for a wide range of businesses such as service bureaus, educational institutions, photographers, software and IT companies, governments, corporations, medical organisations, etc.
PRODUCT TYPE Discproducer
PRODUCT NAME Discproducer PP-100III
PRODUCT CODE C11CH40031
MAIN UNIT
PUBLISHING SPEED
*(Burn & Print) CD 30 discs/hour, Epson-specified CD-R
600 MB data volume, writing speed: Drive max speed: 40 x
DVD 15 discs/hour, Epson recommended DVD-R
3.8 GB data volume, writing speed: Drive max speed: 12 x
BD 8.5 discs/hour, Epson specific BD-R
23.8 GB data volume, writing speed: Drive max speed: 8 x
Printing Only (CD/DVD) 65 discs/hour, bidirectional (fast mode)
45 discs/hour, bidirectional (fine mode)
WRITING SPEED CD Maximum 40 x
DVD-R, DVD+R Maximum 12 x
DVD-R DL, DVD+R DL Maximum 8 x
BD-R Maximum 8 x
BD-R DL Maximum 8 x
POWER CONSUMPTION 52 W (Operation), 27 W (Standby)
ELECTRICAL Rated Voltage AC100V to AC240V
Frequency 50hz to 60Hz
EXTERNAL DIMENSIONS 377mm (w) x 493mm (d) x 348mm (h) (Excluding the AC cable & USB cable)
WEIGHT Approximately 24Kg
(Including stackers and ink cartridges, excluding the AC cable and discs)
ENVIRONMENTAL CHARACTERISTICS Temperature and Relative Humidity 10° C to 35° C, 20% to 80% (no condensation)
EXPECTED LIFETIMES Ink Pad Life Approx. 30,000 printable discs **
HARDWARE
CD/DVD DRIVES Number of Drives 2 drives
PRINTER MODE Print Head Black ink 180 Nozzles, Colour ink 180 Nozzles x 5
Print Direction Bidirectional or unidirectional
Print Resolution - Hi-Speed 1440 dpi x 720 dpi (fast mode)
Print Resolution - Hi Resolution 1440 dpi x 1440 dpi (fine mode)
PRINT AREA Standard setting for outside diameter 116 mm
Outside diameter setting range 70-119.4 mm
Standard setting for inside diameter 45 mm
Inside diameter setting range 18-50 mm
Guaranteed print area 45-116 mm
STACKER CAPACITY Stacker 1,2,3 50 discs (It's possible to print 100 discs without stopping by using both stackers 1 and 2.)
Stacker 4 5 discs
INTERFACE 1 x USB 3.0
Super speed
INK CARTRIDGE Ink Type Dye ink
Colours Yellow, Magenta, Cyan, Light Cyan, Light Magenta, Black
Yield *** 1,000 discs or more (diameter 45 - 116 mm, 16.7% colour sharing, continuous printing, mode setting: Fine)
Cost per disc Cost per Disc calculations are based on Epson's Internal testing. For further details please see Disc yields page.
MAINTENANCE BOX Waste ink maintenance box is replaceable by users on-site in the field. This is available for purchase as a separate consumable item (Model PJMB100).
SOFTWARE (WINDOWS)
Total Disc Maker Installed on the user's computer to publish discs.
Total Disc Monitor Displays the status of JOBs and devices.
Total Disc Setup Installed on user's PC for easy PP-100III setup.
TD Bridge system Incorporation tool to use with other companies' applications, supplied free via the website on product registration. Click here to register.
WRITING DATA EDITING Supported file format
Data files Any files
Audio files WAVE, MP3, WMA
Movie files MPEG1
Output support data CD, audio CD, audio & data CD, Video CD, data DVD, Video DVD, BD
WRITING DATA COPYING Direct copying data CD, music CD, DVD (only single session and Disc-At-Once supported), BD
Image file copying ISO
LABEL EDITING Template Up to 58 templates (EPSON original) + 51 Patterns
Background Full-filled, gradation, graphic, including EPSON original background files (data size, volume label/title), arch style strings
Printing following items
Text strings, automatic inserted strings (published date, created date, counter, number of sheets, number of pages), writing face gearing strings (date size, volume label/title), arch style strings
Graphic BMP, JPEG, TIFF, PNG, EPSON original graphic files (up to 81), trimming, transmit
Thumbnail tile, circle, gearing with writing surface
Folder list Create folder list automatically
Diagram Straight line, rectangle, oval
Export TD Maker original formatted file.
PUBLISHING Publishing modes (number of copies)
Batch mode: 1- 100 CDs/DVDs/BDs, 3 stackers used
Standard mode: 1- 50 CDs/DVDs/BDs, 2 stackers used
External output mode: 1- 5 CDs/DVDs/BDs, 2 stackers & pick-up tray used
Data comparing Data comparing is selectable (audio CD not supported)
Label type Epson specified CD/DVD/BD Label
CD/DVD/BD Premium Label
CD/DVD/BD Label
Number of discs 1 disc to 100 discs (depend on publishing mode)
STATUS MONITOR Job monitoring Job status, Cancelling, Pausing, Restarting
Device monitoring Ink remaining, Drive status, Printing status, Stacker status, Media remaining, USB Mode
SOFTWARE (MAC)
Total Disc Maker Installed on the user's Mac to publish discs.
Total Disc Utility Displays the status of JOBs and devices and change the publish settings.
WRITING DATA EDITING Supported file format
Data files Any files
Audio files WAVE, MP3, AIFF, AAC
Movie files MPEG1
Output support data CD, audio CD, data DVD, Video DVD, BD
WRITING DATA COPYING Direct copying data CD, audio CD, DVD (only single session supported), BD
Image file copying ISO 9660 Level2, UDF Ver1.02, Joliet, HFS+
LABEL EDITING Printing following items
Text strings, automatic inserted strings (published date, created date, counter, number of sheets, number of pages), writing face gearing strings (date size, volume label/title)
Graphic BMP, JPEG, TIFF, PNG, PDF, AI (For PDF and AI files are available only they can be previewed from Finder.)
Barcode JAN8/EAN8,
JAN13/EAN13,
ITF,
CODE128,
PDF417,
QR(model 2),
CODE39,
NW-7
Export Windows bitmap. jpeg, jpeg2000, tiff, png
PUBLISHING Publishing modes (number of copies)
Standard mode: 1- 100
Low volume mode: 1-20 (Stacker 3 is used in this mode)
Data comparing Data comparing is selectable (audio CD not supported)
Label type Epson specified CD/DVD/BD Label
CD/DVD/BD Premium Label
CD/DVD/BD Label
Number of discs 1 disc to 100 discs (depend on publishing mode)
STATUS MONITOR (Total Disc Utility) Job monitoring Job status, Cancelling, Pausing, Restarting
Device monitoring Ink remaining, Drive status, Printing status, Stacker status, Media remaining
REQUIRED SYSTEM
REQUIRED PC ENVIRONMENT Operating System Windows® 7,Windows® 8, Vista SP1 or later; Windows® XP SP2 or later, Windows® 2000 SP4 or later , Server 2008 R2, Server 2008 SP2 or later; and Server 2003/2003 R2 SP2 or later (Windows XP and Server 2003/2003 R2 32 bit only)
CPU Intel® Pentium® 4 Processor 1.4GHz or higher (2.0GHz or higher for Server 2008)
Memory 2Gb or larger (Vista: 1Gb or larger)
HDD 30 Gb available space or larger, (50Gb available space Windows Server 2008) 7,200 rpm or more
Graphics environment XGA or more, 65,536 colours or more
Sound environment A sound device and a supported driver must be installed for music media.
Interface USB 2.0 or USB 3.0
REQUIRED MAC ENVIRONMENT Operating System Mac OS 10.7.3 Lion, Mac OS 10.6.8 Snow Leopard, Mac OS 10.8.2 Mountain Lion
CPU Mac OS X 10.6.8 Snow Leopard : Intel Core Duo 1.83GHz or more, Mac OS X 10.7.3 Lion : Intel 64bit CPU
Mac OS X 10.8.2 Mountain Lion : 2GB or larger
Memory Mac OS X 10.6.8 Snow Leopard : 1GB or larger, Mac OS X 10.7.3 Lion : 2GB or larger, Mac OS X 10.8.2 Mountain Lion: 2GB or larger
Graphics environment Graphics environment: XGA or more
Interface USB 2.0
SUPPORTED MEDIA
SIZE Outside diameter 120 mm ± 0.3 mm
Inside diameter 15 mm + 0.1/-0 mm
Thickness 1.2 mm + 0.3/-0.1 mm
FORM Only standard 12 cm (4.7 inch) discs
TYPE CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
SURFACE Inkjet printable
CONSUMABLES
PRODUCT PRODUCT NAME PRODUCT CODE
Ink cartridge cyan PJIC1(C) C13S020447
Ink cartridge light cyan PJIC2(LC) C13S020448
Ink cartridge light magenta PJIC3(LM) C13S020449
Ink cartridge magenta PJIC4(M) C13S020450
Ink cartridge yellow PJIC5(Y) C13S020451
Maintenance Box PJMB100 C13S020476
WARRANTY 1 year
