Product Description
The HP X9D24A Large Format Dual-Roll PostScript Photo Printer delivers photo-quality prints 2.5 times faster without losing quality. Cut post-processing time up to 20% with the first printer to include an integrated vertical trimmer. Simplify your workflow with new tools in the HP Applications Center.Professional photographers, graphic designers and print service providers who want to create high-impact indoor prints consistently and accurately This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip.
Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Impress the most demanding customers with smooth transitions and sharp details thanks to HP Pixel Control.No need for light inks using new high-definition HP printheads with dual drop technology. Achieve expanded gamut with RGB HP Vivid Photo Inks and the embedded spectrophotometer.Get superior gloss uniformity by upgrading your printer to include HP Gloss Enhancer.
Cut post-processing labor time up to 20% with the first printer to include an integrated vertical trimmer
Spend less time on media changes and adjustments with dual roll support and automatic roll switching
Easily design applications from posters to banners and canvas with the HP Applications Center
No disruption to your workflow, keep using your current RIPs, validated with HP RIP certification program
Get remote visibility and control to better manage your print production environment with HP PrintOS
Deliver high quality with confidence
Print speed 44-in: Fast: 71.4 m²/hr on plain media Normal: 17.2 m²/hr on coated media Best: 4.5 m²/hr on glossy media
Print resolution Up to 2400 x 1200 optimized dpi
Technology HP Thermal Inkjet
Margins Roll: 5 x 5 x 5 x 5 mm (borderless on selected media , or on all media with V-Trimmer ) Sheet: 5 x 17 x 5 x 5 mm
Ink types Pigment-based
Ink drop 7/3 pl dual-drop weight (M, C, PK, CB, G); 6 pl single-drop weight (Y, CR, MK, CG)
Printheads 5 universal printheads (valid for all colors)
Printhead nozzles 2112 per color
Line accuracy ±0.1%
Minimum line width 0.02 mm (PDF addressable @ 1200 dpi)
Color accuracy Median < 1.6 dE2000, 95% of colors < 2.8 dE2000
Short-term color stability < 1 dE2000 in less than 5 minutes
Long-term print-to-print repeatability Average < 0.5 dE2000, 95% of colors < 1.4 dE2000
Max optical density 4 L* min/2.5 D
Handling Dual-roll: Two automatic roll feeds, smart roll-switching, top sheet feed, media output bin, automatic horizontal cutter and vertical trimmer (cuts all HP Z-series printer-qualified media, including most canvas)
Roll size 44-in: 279 to 1118-mm
Sheet size 44-in: 210 x 279 to 1118 x 1676 mm
Standard sheets 44-in: A4, A3, A2, A1, A0
Grammage 80 to 500 g/m²
Print languages (standard) Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL
Printer 44-in: 1802 x 695 x 998 mm
Shipping 44-in: 1950 x 766 x 718 mm
Printer Weight 72-98 kg
Shipping Weight 102-137 kg
What's in the box?
HP DesignJet Z9+dr 44 in PostScript Printer
Printheads
Introductory Ink Cartridges
Printer Stand and Media Bin
Spindle
7.62cm (3in) Core Adapter
Quick Reference Guide
Setup Poster
Power Cord
Product Specifications
Max. Print Width 44inch
Up to Res 2400 x 1200 dpi
5 Universal Printheads
9 ink Cartridges
Vertical Trimmer Included
USB & Network Interface
One Year Limited Warranty
