Product Description
Level up your photography with vibrant, high-quality colour and monochrome printing to be proud of. Versatile, compact and easy to use, this A3+ printer has borderless, fine art and panorama options so you can focus on finding the perfect shot.
Specifications
Print Head / Ink
Type ChromaLife 100+
Number of Nozzles Total 6,144 nozzles, C/M/Y/BK/PC/GY/PM/LGY each 768 nozzles x 8
Ink Tank CLI-65 (C/M/Y/BK/PC/GY/PM/LGY) All dye
Maximum Printing Resolution
Maximum Printing Resolution 4800 (horizontal)1 x 2400 (vertical) dpi
Print Speed
Print Speed Photo(11"x14" image on A3+ with Border)2
Colour/PT-101: approx.1 m 30s
Black/PT-101: approx.2 m 50s
Maximum Printable Paper Size
Top Tray (width) Top Tray: Up to 322.2 mm(12.7 inch, Borderless Printing: Up to 329 mm(A3+)(13 inch)
Manual Feed (width) Manual Feed: Up to 323.4mm(12.7 inch, Borderless Printing: Up to 329 mm(13 inch)
Custom (length) 990.60mm (bordered)
Printable Area
Borderless Printing Top/Bottom/Right/Left margin: each 0 mm
Bordered Printing Top margin: 3 mm, Bottom margin: 5 mm Left/Right margin: each 3.4 mm Recommended Top/Bottom margin for Fine Art Paper : each 25mm
Support Media
Top Tray Plain Paper (64-105 g/m2) / Photo Paper Pro Platinum (PT-101)/Photo Paper Plus Glossy II (PP-201)/ Photo Paper Pro Luster (LU-101)/ Photo Paper Plus Semi-gloss (SG-201)/ Matte Photo Paper (MP-101)/ Red Label Superior 80 g/m2(WOP111)/ Canon Oce Office Colour Paper 80 g/m2(SAT213)/ High Resolution Paper (HR-101N),Photo Paper Glossy (GP-501), Envelope, Light Fabric Iron Transfers(LF-101), Dark Fabric Iron Transfers (DF 101)
Manual Feed Photo Paper Pro Platinum (PT-101)/Photo Paper Plus Glossy II (PP-201)/Photo Paper Pro Luster (LU-101)/ Photo Paper Plus Semi-gloss (SG-201)/ Matte Photo Paper (MP-101)/ Photo Paper Pro Premium Matte (PM-101)/ Premium Fine Art Rough (FA-RG1)/ Photo Paper Glossy (GP-501), Light Fabric Iron Transfers(LF-101), Dark Fabric Iron Transfers (DF 101)
Multi-Purpose Tray Printable Nail Sticker(NL-101)/ Printable Disk
Paper Size
Top Tray A3+/A3/A4/A5/B4/B5/ 7"×10" (18x25cm) / 12"×12" (30x30cm) / 4"x6" (10x15cm) / 5"×7" (13x18cm) / 8"×10" (20 x 25cm) / 10"×12" (25x30cm) / Square 5"(127x127 mm)
Custom size (width 89 mm - 329 mm, length 127 mm - 990.6 mm) Envelopes(DL, COM10)
Manual Feed A3+/A3/A4/B4/LTR/LGL/Ledger/12"×12" (30x30cm)
8"×10" (20 x 25cm) /10"×12" (25x30cm)
Custom size (width 203.2 mm - 330.2 mm, length 254 mm - 990.6 mm)
Multi-Purpose Tray 120 x120 mm
Paper Size (Borderless)
Paper Size (Borderless) A3+/A3/A4/ 7"×10" (18x25cm) / 12"×12" (30x30cm) / 4"x6" (10x15cm / 5"×7" (13x18cm) / 8"×10" (20 x 25cm) / 10"×12" (25x30cm) / Square 5"(127x127 mm)
Paper Handling
Top Tray (Maximum Number) Plain Paper: A4/A5/B5 = 100 B4/A3/ = 50
Photo Paper Pro Platinum (PT-101): L/KG( 4"x6"(10x15cm) = 20 /A3/A4/ 8"×10" (20 x 25cm) = 10 10"×12" (25x30cm) /A3+ = 1
Photo Paper Plus Glossy II (PP-201): (4"x6" (10x15cm) / Square 5"(127 x127mm) = 20 A3 / A4/ 8"×10" (20 x 25cm) = 10 5”x7” (13x18cm) = 10 A3+ = 1
Photo Paper Pro Luster (LU-101): A4 /A3 = 10 A3+ = 1
Photo Paper Plus Semi-gloss (SG-201): ( 4"x6" (10x15cm) = 20 /A4 /A3/ 5"×7" (13x18cm) / 8"×10" (20 x 25cm) = 10 10"×12" (25x30cm) / A3+ = 1
Matte Photo Paper (MP-101): (4"x6" (10x15cm) = 20 A4 /A3 = 10 A3+ = 1
Light Fabric Iron-on Transfers = 1
Dark Fabric Iron-on Transfers = 1
Manual Feed (Maximum Number) Photo Paper Pro Platinum (PT-101): A3/A4/LTR/8"×10" (20 x 25cm) /10"×12" (25x30cm) /A3+ = 1
Photo Paper Plus Glossy II (PP-201): A4/A3/A3+ = 1
Photo Paper Pro Luster (LU-101): A4/A3/A3+ = 1
Photo Paper Plus Semi-gloss (SG-201): A4/A3/8"×10" (20 x 25cm) /10"×12" (25x30cm) /A3+ = 1
Matte Photo Paper (MP-101): A4/A3/A3+ = 1
Photo Paper Pro Premium Matte (PM-101): A4/A3/A3+ = 1
Premium Fine Art Rough (FA-RG1): A4/A3/A3+ = 1
Light Fabric Iron-on Transfers = 1
Dark Fabric Iron-on Transfers = 1
Multi-Purpose Tray 1 (Multi-purpose Tray) *For further details on paper load limits, please refer to the online manual
Paper Weight
Top Tray Plain Paper:64-105 g/m2 Canon Genuine paper (maximum): approx. 380 g/m
Manual Feed Canon Genuine paper (maximum): approx. 380 g/m, or Paper Thickness 0.1 ~0.6 mm or less
Cartridges & Yields
Page Yield (4x6" PT-101) Number of 10x15cm photos
Black (BK): 860 photos*
Grey (GY): 595 photos*
Light Grey (LGY): 965 photos*
Cyan (C): 482 photos*
Photo Cyan (PC): 275 photos
Magenta (M): 610 photos*
Photo Magenta (PM): 320 photos
Yellow (Y): 295 photos
* Estimated Supplemental Yield
Page Yield (A3+ PT-101) Number of A3+ photos
Black (BK): 69 photos*
Grey (GY): 96 photos*
Light Grey (LGY): 139 photos*
Cyan (C): 51 photos
Photo Cyan (PC): 59 photos*
Magenta (M): 77 photos*
Photo Magenta (PM): 54 photos
Yellow (Y): 55 photos
* Estimated Supplemental Yield
Connectivity
Interface USB B Port - Hi-Speed USB
Wired LAN Available
Network type: SNMP/ HTTP/TCP/IP(IPv4/IPv6)
Data rate: 10Mbps/100Mbps (Auto switching)
Security: IEEE 802.1X(EAP-TLS/EAP-TTLS/PEAP)
Wireless LAN Available
Network type: IEEE802.11n/IEEE802.11g/IEEE802.11b/IEEE802.11a
Frequency Band:
2.4GHz Channel : EUR / EMBU
Range: Indoor 50 m ※depends on the transmission speed and conditions
Security: WPA-PSK(AES)
WPA2-PSK(AES)
WPA3-SAE(AES)
WPA-EAP(AES)*
WPA2-EAP(AES)*
WPA3-EAP(AES)*
* IEEE802.1X(EAP-TLS/EAP-TTLS/PEAP) available
System Requirements
Supported Operating Systems Windows 7 SP1, Windows 8.1, Windows 10, Windows 11
Windows Server 2008 R2 SP1, Windows Server 2012 R2,
Windows Server 2016, Windows Server 2019, Windows Server 2022
Mac OS
OS11.7.10 - OS15
Chrome OS
Software Support
Canon Professional Print & Layout Available
Adobe Photoshop / Lightroom Supported via Canon PPL Plugin
Print Applications & Methods
Canon PRINT Inkjet/SELPHY Available
AirPrint Available
Mopria Available
Canon Print Service (for Android) Available
PIXMA Cloud Link Available
WiFi PictBridge Available
Operation Panel
Display 3.0 inch/7.5cm LCD(Display Panel, Color)
Language 33 Languages Selectable: Japanese / English(mm & inch) / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese
Acoustic Noise
Acoustic Noise Plain Paper(A4, Color) = Approx. 42.5db
Photo Paper Pro Platinum (PT-101)(4×6,Color, borderless) = Approx. 42.2db3
Power
Power AC 100 -240 V 50 /60 Hz
Power Consumption
Standby USB Connection to PC Approx 1.1W
Off Approx. 0.05W
Printing / USB Connection to PC approx 17W
Standby All Ports Connected approx. 2.3W
Time to enter Standby Mode approx. 3 min 3 sec <EU only - for ErP Lot 26 regulation>
Dimensions (W x D x H)
Factory Configuration approx. 639 x 379 x 200 mm
Output/ADF Trays Extended approx. 639 x 837 x 416 mm
Weight
Weight approx. 14.1kg
