Product Description
The HP DesignJet Z6 PostScript Printer series delivers high-definition color and detail, a streamlined workflow, and industry-leading security—more quality with fewer inks, faster than ever.
PRECISE—Reveal every subtle detail
Achieve smooth gradients, fine detail, and high-contrast color with HP Pixel Control and high-definition printheads—no light inks needed. HP Vivid Photo Inks deliver water- and fade-resistant prints, indoors and out
FAST—Streamline your workflow
Streamline every step. HP Click software, one-click trimming, automatic roll switching 4, and Productivity modes that increase productivity in printing 5 keep your workflow fast and your reprints to a minimum
SECURE—Protect your work and your information with HP Wolf Pro Security
Your work is valuable. HP Wolf Pro Security helps to protect it with Secure Boot, encrypted storage, secure PIN printing, and fleet-wide security management.
Tech specs
Margins Roll: 5 x 5 x 5 x 5 mm (borderless on selected media , or on all media with V-Trimmer ) Sheet: 5 x 17 x 5 x 5 mm
Printer 66-96 kg
Grammage 80 to 500 g/m²
Handling Dual-roll: Two automatic roll feeds, smart roll-switching, top sheet feed, media output bin, automatic horizontal cutter and vertical trimmer (cuts all HP Z-series printer-qualified media, including most canvas)
Ink drop 7/3 pl dual-drop weight (M, C, PK); 6 pl single-drop weight (Y, CR, MK)
Shipping 97-132 kg
Ink types Pigment-based
Roll size 44-in: 279 to 1118-mm
Thickness Up to 0.8 mm
Printheads 3 universal printheads (valid for all colors)
Sheet size 44-in: 210 x 279 to 1118 x 1676 mm
Technology HP Thermal Inkjet
Print speed 44-in:Fast: 80.5 m²/hr on plain media / Normal: 18.8 m²/hr on coated media / Best: 9.7 m²/hr on glossy media
Line accuracy ±0.1%
Standard sheets 44-in: A4, A3, A2, A1, A0
Print resolution Up to 2400 x 1200 optimized dpi
Printhead nozzles 2112 per color
Minimum line width 0.02 mm (PDF addressable @ 1200 dpi)
Max optical density 4 L* min/2.5 D
Printer (w x d x h) 44-in: 1802 x 695 x 998 mm
Shipping (w x d x h) 44-in: 1950 x 766 x 718 mm
Short-term color stability < 1 dE2000 in less than 5 minutes
Long-term print-to-print repeatability Average < 0.5 dE2000, 95% of colors < 1.4 dE2000
What's in the box?
HP DesignJet Z6 44" PostScript Printer with 5 Year Warranty
Printheads
Introductory Ink Cartridges
Printer Stand and Media Bin
Spindle
7.62cm (3in) Core Adapter
Quick Reference Guide
Setup Poster
Power Cord
Product Specifications
Max. Print Width 44inch
Up to Res 2400 x 1200 dpi
128 GB Standard Memory
3 Universal Print heads
135mm Rolls Diameter
USB & Network Interface
5-Year Limited Warranty
Brochure for HP DesignJet Z6 44-in PostScript Printer + 5 Year Warranty
