Brief Overview
PT-P950NW P-TOUCH ADVANCED MULTI-INTERFACE FOR NETWORK (L AN) USBA WITH BT(OPTIONAL)
Product Description
Label Printer
Auto Cutter: Yes
Compatible Tapes: FLe label , HGe tape , HSe tape , TZe tape
Fonts: Brussels , Gothic , Helsinki , Letter Gothic
Repeating Printing: 5000 copies
Styles & Effects: Bold , Invert , Italic , Normal , Shadow , Shadow light , Surround , Vertical
Printer
Language Simulation: EPSON ESC/P
Max H-Document Size: 1.42 in
Max Printing Width: 1.3 in
Media Sizes: 0.83 in x 1.77 in , Roll (0.14 in) , Roll (0.23 in) , Roll
(0.346 in) , Roll (0.35 in) , Roll (0.46 in) , Roll (0.47 in) , Roll
(0.697 in) , Roll (0.7 in) , Roll (0.929 in) , Roll (0.95 in) , Roll
(1.42 in)
Media Type: Laminated tape
Printer Features: Auto Power Off
Type: Label printer
Printer Output
Max Speed: 141.7 inch/min
Printer Media
Media Feeder Capacity: 1 roll
Media Feeder Max Format: Roll (1.42 in)
Media Feeder Qty: 1
Media Load Type: Manual
Service
Support Details Full Contract Period: 2 years
Support Details Location: Pick-up and return
Support Details Type: Limited warranty
System Requirements
Min Operating System: Android 1.6 or later , Apple iOS 3.0 or later ,
Apple MacOS X 10.10.x , Apple MacOS X 10.8.x , Apple MacOS X 10.9.x ,
Microsoft Windows 7 (32/64 bits) , Microsoft Windows Server 2008 ,
Microsoft Windows Server 2008 R2 , Microsoft Windows Server 2012 ,
Microsoft Windows Server 2012 R2 , Microsoft Windows Vista (32/64 bits) ,
Windows 10 (32/64 bits) , Windows 8 (32/64 bits)
Miscellaneous
Color Category: Black
Media Included: 1 36 mm x 8 m black on white TZe tape
Cable
Connectivity Details Type: USB cable
Environmental Parameters
Humidity Range Operating: 20 - 80%
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Header
Brand: Brother
Compatibility: Android , Apple iOS , Mac , PC
Manufacturer: BROTHER MOBILE SOLUTIONS
Model: PT-P950NW
Packaged Quantity: 1
Product Line: Brother P-Touch
Interface Required
Total Qty: 1
Type: USB 2.0
Connector Type: RJ-45
Type: LAN
Networking
Type: Print server
Power Device
Form Factor: External
Frequency Required: 50/60 Hz
Nominal Voltage: AC 120/230 V
Type: Power adapter
Printer Fonts
Font Included Type: TrueType
Fonts Included Qty: 1
Scanner
Type: None
Dimensions & Weight
Depth: 7.6 in
Height: 5.7 in
Weight: 3.33 lbs
Width: 4.6 in
Barcode
Barcodes: Aztec code , Codabar , Code 128 , Code 39 , Data Matrix ,
EAN-13 , EAN-8 , GS1 DataBar , GS1 DataBar Expanded , GS1 DataBar
Limited , GS1 DataBar Omnidirectional , GS1 DataBar Stacked
Omnidirectional , ISBN , ITF 2 of 5 , MaxiCode , PDF417 , Postnet , QR
code , RSS-14 , UCC/EAN-128 , UPC-A , UPC-E
Cable Details
Included Qty: 1
Chassis
Built-In Devices: Cutter
Dimensions & Weight (Shipping)
Shipping Depth: 10.5 in
Shipping Height: 13.1 in
Shipping Weight: 6.1 lbs
Shipping Width: 6.5 in
Document & Media Handling
Max Media Size: Roll (1.42 in)
Media Size Class: Other
Media Type Class: Other
Environmental Standards
ENERGY STAR: Yes
Office Machine
Functions: Printer
Printing Output Type: Monochrome
Printing Technology: Thermal transfer
Type: Printer
PC Connectivity
PC Connection: LAN , USB 2.0 , Wi-Fi(n)
Printing
Max Printing Speed B/W: 141.7 inch/min
Max Resolution B/W: 360 x 720 dpi
Service & Support
Type: 2 years warranty
What's in the box?
PT-P950NW, Quick Setup Guide, TZe tape (36mm Black on White Laminated 8 Metre Tape), Editor Software on CD, AC Adaptor, USB Cable
Product Specifications
Up to Print Speed 60mm/sec.
Up to Resolution 360 dpi
Mobile Device Printing
1 Roll Media Feeder Capacity
Auto Cutter
USB & Network Interface
2 Year Warranty
Brochure for Brother P-touch PT-P950NW Label Printer
