Product Description
ZEBRA MIDRANGE ZT411 4IN 203DPI T/T MULT PEEL/RFID
Keep critical operations moving with Zebra’s durable ZT400 Series printers constructed with an all-metal frame. Featuring advanced technology—including a large color touch display and versatile connectivity options—these printers take performance to a new level and are adaptable for your evolving needs. Intuitive to integrate and operate, they feature Zebra’s Print DNA software powered by Link-OS to deliver unparalleled intelligence and innovation for exceptional performance and simplified remote manageability. Easily replace legacy printers using ZPL, EPL or non-Zebra command languages.
Specifications are provided for reference and are based on testing the ZT411™ printer using genuine Zebra® supplies. Results may vary in actual application settings or when using other-than-recommended Zebra supplies. Zebra recommends always qualifying any application with thorough testing.
Features
Thermal transfer and direct thermal printing
Thin film printhead with E3â„¢ Element Energyâ„¢ Equalizer for superior print quality
203 dpi print resolution (8 dots / mm)
Print speed per second up to 14" (356 mm / second)
USB 2.0, high speed
Bluetooth® 4.1 (including Apple®)
Dual USB Host
512 MB Flash memory (64 MB User Available)
Print Touchâ„¢ application
Link-OS®-enabled
Technical Specs
Memory
Standard Memory 256 MB
Software
Software Included Link-OS
Warranty
Limited Warranty 12 Month
Interfaces/Ports
USB Yes
USB Host Yes
Technical Information
Application/Usage Industrial
Desktop
Barcode Symbology Supported Code 128-A
UPC
Data Matrix
UPC-A
Aztec Code
MSI
Code 49
Codablock
EAN-8
Interleaved 2 of 5
EAN With 2 and 5 Digit Extension
Code 39
PDF417
Micro PDF
ISBT-128
Plessey
RSS-14
TLC 39
Industrial 2 of 5
Code 93
UPC-E
Code 128-B
Code 11
Maxi Code
Code 128-C
Standard 2 of 5
POSTNET
Planet Code
LOGMARS
QR Code
Codabar
UCC Case Codes
EAN-13
Maximum Print Width 103.89 mm (4.09")
Recommended Use Label Print
Connectivity Technology Wired
Features Rugged
Bi-color LED
Maximum Mono Print Speed 356 mm/s
Peel Facility Yes
Print Color Capability Monochrome
Maximum Print Length 3.99 m
Optional Connectivity Wireless LAN
Serial (RS-232)
Parallel
Maximum Print Resolution (dpi) 203
Display & Graphics
Display Screen Yes
Screen Size 10.9 cm (4.3")
Display Screen Type LCD
Power Description
Input Voltage 120 V AC
230 V AC
Power Source AC Supply
Environmental Conditions
Storage Relative Humidity 5% - 85%
Storage Temperature -40°C - 60°C
Operating Temperature 0°C - 40°C
Operating Relative Humidity 20% - 85%
Network & Communication
Bluetooth Yes
Ethernet Yes
Ethernet Technology Fast Ethernet
Network Ready Yes
Physical Characteristics
Weight (Approximate) 16.33 kg
Height 323.9 mm
Width 269.2 mm
Depth 495.3 mm
Fonts & Emulation
Language Emulation ZPL II
EPL
ZPL
ZBI 2.0
XML
Miscellaneous
Platform Supported PC
Certifications & Standards
TUVus
CE Marking
FCC-B
ICES-003
VCCI
C-Tick
NOM
S-Mark (Arg)
CCC
CU
BSMI
KCC
SABS
IN-Metro
Energy Star Yes
Power Cable Localization AUS
EU
UK
JP
General Information
Product Type Direct Thermal/Thermal Transfer Printer
Manufacturer Part Number ZT41142-T3P00C0Z
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZT411
Product Name ZT411 Industrial Printer
Product Series ZT400
Brand Name Zebra
Media Types & Handling
Media Thickness 250 µm
Maximum Roll Diameter 203.20 mm
Media Type Notch
Die-cut Label
Black Mark
Continuous Label
Linered Label
Continuous Paper
Label
Media Sensor Transmissive Media Sensor
Reflective Media Sensor
Maximum Label Width 114 mm
Maximum Label Length 990.60 mm
What's in the box?
Printer Unit
Starter Roll of label Stock
Power cord
User guide
Safety guide
Product Specifications
Max. Mono Print Speed 356mm/s
Max. Print Resolution 203dpi
256MB Standard Memory
Max. Roll Diameter 203mm
EPL, ZPL & ZPL Languages
USB, Network & Bluetooth
One-Year Limited Warranty
