Product Description
ZEBRA MIDRANGE ZT421 6IN 300DPI T/T MULTI F/PEEL
Specifications are provided for reference and are based on testing the ZT421™ printer using genuine Zebra® supplies. Results may vary in actual application settings or when using other-than-recommended Zebra supplies. Zebra recommends always qualifying any application with thorough testing.
Features
Thermal transfer and direct thermal printing
Thin film printhead with E3™ Element
Energy™ Equalizer for superior print quality
203 dpi print resolution (8 dots / mm)
Print speeds per second up to 12" (305 mm / second)
Technical Specs
Memory
Standard Memory 256 MB
Power Description
Power Source AC Supply
Warranty
Limited Warranty 12 Month
Interfaces/Ports
USB Yes
Serial Port Yes
Miscellaneous
Platform Supported PC
Energy Star Yes
Network & Communication
Bluetooth Yes
Ethernet Yes
Media Types & Handling
Maximum Roll Diameter 203 mm
Media Type Label
Gap
Die-cut Label
Continuous Label
Notch
Black Mark
Maximum Label Width 171 mm
Maximum Label Length 990.60 mm
Physical Characteristics
Weight (Approximate) 20.41 kg
Height 324 mm
Width 336 mm
Depth 495 mm
General Information
Product Type Direct Thermal/Thermal Transfer Printer
Manufacturer Part Number ZT42163-T4P0000Z
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZT421
Product Name ZT421 Industrial Printer
Brand Name Zebra
Technical Information
Application/Usage Industrial
Maximum Print Width 167.64 mm (6.60")
Recommended Use Label Print
Maximum Mono Print Speed 254 mm/s
Print Color Capability Monochrome
Maximum Print Length 1143 mm
Maximum Print Resolution (dpi) 300
Product Specifications
Max. Mono Print Speed 254mm/s
Max. Print Resolution 203dpi
256MB Standard Memory
Max. Roll Diameter 203mm
EZPL Programming Languages
USB, Network & Bluetooth
One-Year Limited Warranty
Brochure for ZEBRA MIDRANGE ZT421 (ZT42163-T4P0000Z) 6IN 300DPI Industrial Printer
