Product Description
Functions Print
Printer Type Laser Printer
Product Dimensions (Width X Depth X Height) 373 mm × 388 mm × 257 mm
Weight 9.5 kg
Print Speed Up to 48 (A4) / Up to 50 (Letter) ppm
Paper Type Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick
Paper Size A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch
Maximum Paper Capacity Up to 1,390 sheets of 80 gsm plain paper (with Added Optional Trays)
Print
Resolution Up to 1200 x 1200 dpi
2-Sided (Duplex) - Printing Paper Type Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) - Paper Size A4, Letter, Legal, Mexico Legal, India Legal, Folio (Paper sizes other than A4 are supported only in some countries.)
Paper handling
Tray #1 - Maximum Paper Weight 60 to 163 gsm (16 to 43 lb)
Tray #1 - Maximum Paper Capacity Up to 250 sheets of 80 gsm plain paper
Tray #1 - Paper Size A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper)
Tray #2 - Maximum Paper Weight 60 to 120 gsm (16 to 32 lb)
Tray #2 - Maximum Paper Capacity
LT-5505: Up to 250 sheets of 80 gsm plain paper
LT-6505: Up to 520 sheets of 80 gsm plain paper
Multi-purpose Tray - Maximum Paper Weight 60 to 230 gsm (16 to 60 lb)
Multi-purpose Tray - Paper Size
Width: 69.8 to 215.9 mm (2.75" to 8.5")
Length: 127 to 355.6 mm (5" to 14")
Envelope: COM-10, DL, C5, Monarch Multi-purpose Tray - Maximum Paper Capacity Up to 100 sheets of 80 gsm plain paper
Paper Output
Up to 150 sheets of 80 gsm plain paper (face-down delivery to the face-down output paper tray)
1 sheet (face up delivery to the face up output tray)
Connectivity
WiFi Direct Yes
Connectivity Hi-SpeedUSB2.0, IEEE 802.11a/b/g/n (Infrastructure Mode), IEEE 802.11a/g/n (Wi-Fi Direct), 10Base-T/100Base-TX/1000Base-T
Display & Memory
Display Type 1 Line LCD (16 characters)
Memory Capacity 256 MB (For Australia)
512 MB (For Korea and Taiwan and African countries) 1GB
Operation
Power Source 220 - 240 V AC 50/60 Hz
Power Consumption - Printing Approximately 670 W
Power Consumption - Ready Approximately 31 W
Power Consumption - Sleep Approximately 5.5 W
Power Consumption - Power Off Approximately 0.05 W
Noise Level 54.0 dB (A)
Supported Operating Systems
Supported OS Windows 10 Server 2012 / 2012 R2 / 2016 / 2019
Software and Apps
Mobile Apps 31/01/2023
Support Center, Print Service Plugin, Mobile Connect
