Product Description
Featuring a sleek, modern design, the compact TM-m50 POS thermal receipt printer meets the needs of businesses both now and in the future. It can be dynamically shared by tablets, smartphones and PC-POS or cloud POS systems.
The TM-m50 provides similar capabilities to a traditional POS printer including USB connectivity and 180dpi. High volume POS customers will benefit from fast print speeds of up to 350mm/s, and be confident that the printer is supported by Epson's proven quality and reliability.
KEY FEATURES & BENEFITS
Sleek, compact and stylish design 3" thermal receipt printer supports traditional, cloud based and mPOS/tablet POS systems
Connect to multiple devices - printer can be dynamically shared by legacy POS terminals, tablets and mobile devices, as well as cloud servers and POS peripherals
Triple-interface connectivity to help future-proof growing businesses - maximum flexibility with built-in USB, Ethernet plus options for wireless technologies
Online ordering ready - Server Direct Print technology enables the printer to retrieve data from the Internet1
Fast, reliable receipt printing - speeds up to 350 mm/sec; printhead life of 200 km, auto cutter life of 2.2 million cuts
Smart connectivity - share data using a single USB cable (cable not included); charge smartphones and tablets
USB-Network-Tethering - provides network connectivity from the printer to a tablet
Reliable and easy to use
Epson is a market leader in POS printing with a heritage of producing high-quality and reliable systems. The TM-m50 is a highly intuitive out-of-the-box solution that features: fast print speeds of up to 350mm/s, enhanced printhead and auto-cutter, and flexible drop-in paper loading (front or top).
Adaptable
Quickly and easily customise receipts with logos and promotional messages. Advance graphics and barcodes using high-quality, multiple greyscale printing are also fast and simple to produce.
The TM-m50 is a feature packed, high performance solution with the legacy features required to allow customers seamless integration into their current systems.
Paper saving
Using backward paper feeding, or printing the logo when the receipt is cut, can shorten receipt lengths reducing paper costs and consumption by up to 30%.
Connectable
A single printer can be dynamically shared in mixed POS environments combining PC and Tablet solutions
Features
Share the printer easily and efficiently with various other systems with the help of built-in Ethernet port
Produce high-quality documents with this monochrome printer to increase your productivity
A smart and inexpensive solution to print temporary documents
Conveniently print your receipts
Technical Specs
Fonts & Emulation
Language Emulation ePOS
Technical Information
Application/Usage Desktop
Mobile
Barcode Symbology Supported Composite Symbology
Code 93
Code 39
Code 128
Codabar (NW-7)
AZTEC
2D
EAN/JAN-8
UPC-E
UPC-A
QR Code
PDF417
Maxi Code
ITF
GS1-128
GS1 DataBar
EAN/JAN-13
Data Matrix
Recommended Use Receipt Print
Connectivity Technology Wired
Features Compact
Print Head Life 200
Installation Horizontal/Vertical
Print Color Capability Monochrome
Mean Time Between Failures (MTBF) 41.1 Year
Mean Cycles Between Failures (MCBF) 70000000
Character Sets 18 International
95 Alphanumeric
128 x 43 Graphic
Optional Connectivity Wireless LAN
Near Field Communication (NFC)
Fonts Included Kanji Font A: 24 x 24 24 cpl;
Font A: 12 x 24 42 cpl (default); Font B: 9 x 24 56 cpl,
Kanji Font B: 16 x 16, 32 cpl (Korean)
Maximum Print Resolution (dpi) 180
Interfaces/Ports
USB Yes
USB Host Yes
Cutter
Cutting Method Automatic
Cutter Yes
Cutter Life 2200000 Cuts
Network & Communication
Bluetooth Yes
Ethernet Yes
Ethernet Technology Fast Ethernet
Media Types & Handling
Maximum Roll Diameter 83.06 mm
Media Type Receipt
Media Sensor Paper End Sensor
Maximum Label Width 83 mm
Power Description
Input Voltage 120 V AC
230 V AC
Power Source Power Adapter
AC Supply
Physical Characteristics
Weight (Approximate) 1.30 kg
Height 127 mm
Width 127 mm
Depth 127 mm
Product Color Black
Miscellaneous
Package Contents
TM-m50-212 Direct Thermal Printer
Roll Paper
AC Adaptor
AC Cable
Spacer for 58mm Paper
Power Switch Cover
Platform Supported PC
iOS
Android
Cables Included AC
Power Adapter Included Yes
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number C31CH94212
Manufacturer Website Address http://www.epson.com.au
Manufacturer Epson Corporation
Product Model TM-m50-212
Product Name TM-m50-212 Direct Thermal Printer
Product Series TM-m50
Brand Name Epson
