Product Description
Built for medium and large work groups, this A4 versatile printer is ideal for businesses searching to take their costs to a minimum while enjoying remarkable productivity and color-rich output.
ECOSYS makes your office more sustainable and efficient
Kyocera solutions always work with the environment in mind, but the ECOSYS range do this more than any other product on the market.
Multi-functional products for day-to-day tasks
Kyocera provides the industry’s most comprehensive line of award-winning low to high volume devices.
A4 printer for all needs
High quality, high reliability and high efficiency are essentia
Specifications
General
General type Colour printer for A4 format
Engine speed Up to 45 pages A4 per minute in colour and b/w
Warm-up time Approx. 20 seconds or less
Power consumption Printing: 576.8 W; Ready mode: 11.8 W Sleep-mode: 0.4 W
Warranty 1-year warranty as standard.** KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions.
Paper handling
Input capacity
Multi-purpose tray: 100 sheets (75 g/m2 equivalent), 110 sheets (64 g/m2 equivalent); 60 – 220 g/m2; A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (70 x 140 to 216 x 356 mm), Banner paper up to 1220 mm; Standard universal paper cassette: 550 sheet with 75 g/m2, 600 sheet with 64 g/m2; 60 – 220 g/m2; A4, A5,A6, B5, B6, Letter, Legal, Folio, Custom (105 x 140 to216 x 356 mm)
Max. input capacity with options Max. input capacity with options: 2,850 sheets with 75 g/m2, 3,110 sheets with 64 g/m2
Duplex unit Standard duplex unit; 60–163 g/m2; A4(Legal) - A6R(StatementE)
Max. output capacity 500 sheets (Equivalent to 80 g/m2) face down with paper full sensor
Print
Processor ARM Cortex-A9 Dual core1.2 GHz
Fonts 93 outline fonts (PCL), 93 fonts (KPDL 3), 8 fonts( Windows Vista), 1 Bitmap font 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Features Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, Private Print quick copy, proof and hold, job storage and job management functionality
Applicable OS All current Windows operating systems, MAC OS X Version 10.8 or higher, Unix, Linux as well as other operating systems on request
Options and Consumables
Paper handling Options
General type
Paper feeder PF-5150
Capacity (sheets) 500 sheets
Dimensions (W x D x H) 380 x 410 x 121 mm
Paper size 60 - 120g/m2, A4, A5, B5, Letter, Legal Custom (92 - 216 x 162 - 356 mm
Consumables
TK-5390C Average continuous cyan toner yield 13,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous cyan toner yield 6,000 pages in accordance with ISO/IEC 19798.
TK-5390K Average continuous black toner yield 18,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous black toner yield 8,000 pages in accordance with ISO/IEC 19798.
TK-5390M Average continuous magenta toner yield 13,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous magenta toner yield 6,000 pages in accordance with ISO/IEC 19798.
TK-5390Y Average continuous yellow toner yield 13,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous yellow toner yield 6,000 pages in accordance with ISO/IEC 19798.
Options
HD-17 64 GB for easy document management
HD-18 256 GB SSD hard disc for easy document management
HD-19 512 GB SSD hard disc for easy document management
IB-37 Wireless Network Interface (USB: 5GHz/2.4GHz)
IB-38 Wireless Network Interface (USB: 2.4GHz)
IB-50 Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT
IB-51 Wireless LAN Interface (802.11b/g/n)
KYOmulticode SD 3 Contains all the functionalities of PCL Barcode Flash plus Unicode font “Andale Mono World Type“ which allows the user to print Asian fonts (Japanese, Korean, current and traditional Chinese)
MD3-1024 1,024 MB RAM Expansion
MDDR3-2GB 2,048 MB RAM Expansion
PCL Barcode SD Adds additional one- and two-dimensional barcodes to the KYOCERA device (as well as the resident and machine-readable fonts OCR-A, OCR-B)
Scan extension Kit (A) AC Scan to searchable PDF (embedded OCR) or to MS Office (docx, xlsx, pptx), HDD, SSD or SD-card is needed.
UG-33 ThinPrint support
UG-35 TPM (Trusted Platform Module)
USB IC Card Reader + Card Authentication Kit (B) Support for various authentication keys available
Product Specifications
Up to 45ppm Colour & Mono
Up to Res 1200 x 1200 dpi
500 Sheet Input Tray
1 GB Standard Memory
Auto Double-Sided Printing
USB & Network Interface
One-Year On-site Warranty
