Brief Overview
A full-featured HP Enterprise Flow MFP that streamlines digital
workflow with advanced HP Flow solutions, safeguards business data and
documents with a robust suite of top-flight security features, and
offers simple, efficient mobile printing.
Product Description
Functions
Print, copy, scan, fax, digital send,print from Easy Access USB, print from Easy Access USB, scan to Sharepoint
Multitasking supported
Yes
Printing specifications
Print speed black:
Normal: Up to 60 ppm 8
First page out (ready)
Black: As fast as 8.5 sec 9
Duty cycle (monthly, A4)
Up to 250,000 pages 10
Recommended monthly page volume
5,000 to 28,000 11
Print technology
Laser
Print quality black (best)
Up to 1200 x 1200 dpi
Print languages
HP PCL 6
HP PCL 5 (HP PCL 5 driver available from the Web only)
HP postscript level 3 emulation
native PDF printing (v 1.7)
Apple AirPrint™
Processor speed
800 Mhz
Automatic paper sensor
No
Connectivity
HP ePrint capability
Yes
Mobile printing capability
HP ePrint, Apple AirPrint™, Mobile Apps, optional Touch to Print,
optional Wireless Direct printing, optional Touch to Authenticate 5
Wireless capability
Optional, wireless enabled with purchase of HP Jetdirect 2700w USB
Wireless Print Server J8026A or HP Jetdirect ew2500 802.11b/g Wireless
Print Server J8021A
Wireless direct and NFC enabled with purchase of HP Jetdirect 2800w NFC/Wireless Direct Accessory J8029A
Connectivity, standard
Hi-Speed USB 2.0 port
built-in Gigabit Ethernet 10/100/1000Base-TX network port
Fax
Network ready
Standard (built-in Gigabit Ethernet)
Connectivity, optional
HP Jetdirect 2700w USB Wireless Print Server J8026A
HP Jetdirect 2800w NFC/Wireless Direct Accessory J8029A
HP Jetdirect ew2500 802.11b/g Wireless Print Server J8021A
Minimum system requirements
Windows full software installs supported on: Windows 8 & 8.1
(32/64-bit), Windows 7 (32/64-bit), Windows Vista (32/64-bit), Windows
XP 32-bit (SP2 or higher)
Mac full software installs: OS X 10.7 Lion, OS X 10.8 Mountain Lion, OS X 10.9 Mavericks
Mobile OS native print support: iOS, Android, Windows 8 RT
Other OSs driver support: Debian (5.0, 5.0.1, 5.0.2, 5.0.3) (supported
by the automatic installer), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12,
12.0), HPUX 11 and Solaris 8/9, Linux (9.4, 9.5), Red Hat Enterprise
Linux 5.0 (supported with a pre-built package), SUSE Linux (10.3, 11.0,
11, 11.1, 11.2), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04)
CD-ROM or DVD drive, or Internet connection
Dedicated USB or network connection or Wireless connection
200 MB available hard disk space
OS X 10.7 Lion, OS X 10.8 Mountain Lion, OS X 10.9 Mavericks
Internet
USB
1 GB HD
Compatible operating systems
Windows XP (SP3) (32-bit), Windows XP (SP3) (64-bit), Windows 7
(Including Starter Edition 32-bit), Windows 7 (Including Starter Edition
64-bit), Windows Vista (Including Starter Edition 32-bit), Windows
Vista (64-bit), Windows 8 Basic (32-bit), Windows 8 Pro (32-bit),
Windows 8 Enterprise (32-bit), Windows 8 Enterprise N (32-bit), Windows 8
Basic (64-bit), Windows 8 Pro (64-bit), Windows 8 Enterprise (64-bit),
Windows 8 Enterprise N (64-bit), Windows 8.1 (64-bit)
OS X 10.7 Lion, OS X 10.8 Mountain Lion, OS X 10.9 Mavericks
Mobile Operating Systems: iOS, Android, Windows 8 RT
Other Operating Systems: Debian (5.0, 5.0.1, 5.0.2, 5.0.3) (supported by
the automatic installer), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12,
12.0), HPUX 11 and Solaris 8/9, Linux (9.4, 9.5), Red Hat Enterprise
Linux 5.0 (supported with a pre-built package), SUSE Linux (10.3, 11.0,
11, 11.1, 11.2), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04)
14
Memory specifications
Memory, standard
1.5 GB (System Memory)
Memory, maximum
2.0 GB (System Memory)
Hard disk
Standard, minimum 320 GB HP High-Performance Secure Hard Disk (AES 256 hardware encryption or greater)
Paper handling
Paper handling input, standard
100-sheet multipurpose tray
three 500-sheet input trays
one 1500 sheet input tray
100-sheet automatic document feeder
Paper handling input, optional
Optional envelope feeder
Paper handling output, standard
900-sheet stapler stacker
Maximum output capacity (sheets)
Up to 900 sheets
Duplex printing
Automatic (standard)
Media sizes supported
Tray 1: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), 10 x 15 cm, Oficio (216 x
340 mm), 16K, envelopes (C5, B5, C6, DL ISO), Postcard (JIS single and
double); Trays 2, 3, 4: A4, A5, RA4, B5 (JIS), Oficio (216 x 340 mm),
16K; Tray 5: A4
Media sizes, custom
Tray 1: 3 x 5 to 8.5 x 14 in; Trays 2, 3, 4: 5.83 x 8.27 to 8.5 x 14 in
Media sizes, custom
Tray 1: 76 x 127 to 216 x 356 mm; Trays 2, 3, 4: 148 x 210 to 216 x 356 mm
Media types
Paper (plain, light, bond, recycled, heavy, extra heavy, cardstock,
pre-printed, pre-punched, colored, rough, heavy rough), mono
transparency, labels, letterhead, envelope, heavy envelope
Media weight, supported
Tray 1: 60 to 200 g/m²; Trays 2, 3, 4, 5: 60 to 120 g/m²
Media weights, supported ADF
60 to 120 g/m²
Scanner specifications
Scanner type
Flatbed, ADF
Scan file format
Digital Send: PDF, JPEG, TIFF, MTIFF, XPS, PDF/A, TEXT (OCR), Unicode
TEXT (OCR), RTF (OCR), Searchable PDF (OCR), Searchable PDF/A (OCR),
HTML (OCR), CSV (OCR); Scan to easy access USB: PDF, JPEG, TIFF, MTIFF,
XPS, PDF/A, TEXT (OCR), Unicode TEXT (OCR), RTF (OCR), Searchable PDF
(OCR), Searchable PDF/A (OCR), HTML (OCR), CSV (OCR)
Scan resolution, optical
Up to 600 dpi
Scan size (flatbed), maximum
216 x 356 mm
Scan size (ADF), maximum
216 x 356 mm
Scan size (ADF), minimum
68 x 148 mm
Scan speed (normal, A4)
Up to 65 ppm (b&w), up to 63 ppm (color) 13
Recommended monthly scan volume
26,750 to 44,500
Duplex ADF scanning
Yes, single pass duplexing ADF
Automatic document feeder capacity
Standard, 100 sheets
Digital sending standard features
Scan to e-mail; Save-to-Network Folder; Scan to Sharepoint; Save-to-USB
drive; Send to FTP; Send to LAN Fax; Send to Internet Fax; Local Address
Book; SMTP over SSL; OCR; Scan to HP Flow CM
File formats, supported
Digital Send: PDF, JPEG, TIFF, MTIFF, XPS, PDF/A, TEXT (OCR), Unicode
TEXT (OCR), RTF (OCR), Searchable PDF (OCR), Searchable PDF/A (OCR),
HTML (OCR), CSV (OCR)
Scan to easy access USB: PDF, JPEG, TIFF, MTIFF, XPS, PDF/A, TEXT (OCR),
Unicode TEXT (OCR), RTF (OCR), Searchable PDF (OCR), Searchable PDF/A
(OCR), HTML (OCR), CSV (OCR)
Print from easy access USB: PDF, PS, Print Ready files (.prn, .pcl, .cht)
Scan input modes
Front panel applications: Copy, E-mail, Save to Network Folder, Save to
USB, Save to Device Memory, Open Extensibility Platform (OXP)
applications
Copier specifications
Copy speed (normal)
Black: Up to 60 cpm 6
Copy resolution (black text)
Up to 600 x 600 dpi (Flatbed), 300 x 600 dpi (ADF)
Copy resolution (color text and graphics)
Up to 600 x 600 dpi (Flatbed), 300 x 600 dpi (ADF)
Copy reduce / enlarge settings
25 to 400%
Copies, maximum
Up to 9999 copies
Fax specifications
Faxing
Yes
Fax transmission speed
3 sec per page 15
Fax memory
Incoming fax can be stored to disk
Fax resolution
Up to 300 x 300 dpi
Speed dials, maximum number
Up to 100 (each can contain 100 numbers)
Broadcast locations
100
Power and operating requirements
Power
110-volt input voltage: 100 to 127 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz),
12 A; 220-volt input voltage: 220 to 240 VAC (+/- 10%), 50 Hz (+/- 2
Hz), 6 A (Not dual voltage, power supply varies by part number with #
Option code identifier)
Power consumption
970 watts (Printing), 6.5 watts (Sleep), 0.1 watts (Manual Off), 1.60
watts (Auto-Off/Wake on LAN), 0.1 watts (Auto-Off/Manual On) 3
Energy efficiency
ENERGY STAR® qualified
Blue Angel
CECP
EPEAT® Silver
Operating temperature range
15 to 32.5°C
Operating humidity range
30 to 70% RH
Acoustic power emissions (ready)
4.4 B(A) 7
Acoustic pressure emissions bystander (active, printing)
58 dB(A) 7
Dimensions and weight
Minimum dimensions (W x D x H)
911 x 643 x 1110 mm 1
Maximum dimensions (W x D x H)
1191 x 757 x 1142 mm (with multipurpose tray, keyboard and output bin fully extended) 1
Weight
91.2 kg
Package weight
124.33 kg (AMS, EMEA), 128.45 kg (APJ)
What's included
What's in the box
HP LaserJet Enterprise Flow MFP M630z
Black print cartridge
CD(s) with software and documentation
Getting Started Guide
Power cord
Telecom cable
Keyboard overlay kit
Cable included
No, please purchase USB cable separately.
Replacement cartridges
HP 81A Black Original LaserJet Toner Cartridge (10,500 yield) CF281A
HP 81X High Yield Black Original LaserJet Toner Cartridge (25,000 yield) CF281X
Software included
Windows: HP Installer/Uninstaller, HP PCL 6 print driver, DXP (Device
Experience), HP Help & Learn Center, HP Send Fax, HP Update, Product
Registration Assist, HP Web Services Assist (HP Connected), .NET 3.5
SP1 (only installed for older Windows operating systems that lack),
Setup Scan To Folder and Email; Mac: Welcome Screen (Redirects users to
HP.com, or OS App Source for LaserJet Software)
Warranty
One-year, onsite warranty
What's in the box?
HP LaserJet Enterprise MFP M630z
Black print cartridge (10500 pages)
CD with software drivers and documentation
Documentation (Hardware Install Guide)
Power cord
HP Jetdirect Gigabit Ethernet Print Server (embedded)
100-sheet multipurpose tray 1
500-sheet input tray 2
Automatic duplexer (built-in)
Hard Drive
Product Specifications
Up to 57ppm in Mono
Up to Resolution 1200 x 1200 dpi
2 x 500 Sheet Input Tray
20.3cm Colour Touchscreen
Automatic Double Sided Printing
USB & Network
One Year Return to Base Warranty
Brochure for HP Laserjet Enterprise M630z A4 Mono Multifunction Printer
