Brief Overview
PDS-6000 80PPM 100 SHT ADF USB3 BUSINESS SCANNER
Product Description
The Brother PDS-6000 is a fast, robust and accurate professional
document scanning solution with ultra fast 2-sided (duplex) scan
capability of up to 80ppm and a large 100-sheet A4 Automatic Document
Feeder (ADF) capable of scanning a wide range of documents from receipts
to reports, plus advanced roller and multi-feed detection systems;
makes it the ideal business choice for for high volume batch scanning
and digital archiving.
General
ModelPDS-6000EngineDesktopFunctionsSheetfed Colour Scanner Standard
Memory512 MBCarrier Sheet ScanYesPlastic Card Scan Thickness - 16 mil to
30 mil (0.4 mm to 0.76 mm)
Size - 70-95mm(L) x 51-55(W) x 0.76mm(Thick)Multi Feed SensorYes
Display
LCD Display16 Characters x 2 lines LCD with Backlight
Paper Handling
Output Paper Capacity Up to 100 sheets ADF Up to 100 sheets / 1 Card
with Carrier SheetMedia Weight GeneralSingle Sheet: 28 to 400 gsm
Multiple Sheets: 28 to 400 gsm
Plastic Card: 0.76mm(Thick)
(Embossed: up to 1.25mm)Media Size General Single Sheet: 51 to 218 mm(W) x 54 to 5994 mm(L)
Mulitple Sheet: 51 to 218 mm(W) x 54 to 356 mm(L)
Plastic Card: 70-95mm(L) x 51-55(W) x 0.76mm(Thick), Embossed: up to
1.25mmMedia Size ADFSingle Sheet: 51 to 218 mm(W) x 54 to 5994 mm(L)
Mulitple Sheet: 51 to 218 mm(W) x 54 to 356 mm(L)
Plastic Card: 70-95mm(L) x 51-55(W)Media Type GeneralSingle Sheet: All types (using carrier sheet)
Multiple Sheets: Plain Paper, Business Card, Plastic Card
Digital Scanner
Scanner Colour/MonoColour Scanner Colour Depth48 bit input / 24 bit
output colour Scanner TypeSheet Fed Digital Scanning Technology Dual
CISScan Speed Simplex: Colour/Mono: 80ppm (A4@200/300dpi), 20ppm
(A4@600dpi)
Duplex: Colour/Mono: 80ppm/160ipm (A4@200/300dpi), 20ppm/40ipm
(A4@600dpi)Scanner Resolution (Optical)Up to 600 x 600 dpi Scanner
Resolution (Interpolated)Up to 600 x 600 dpi2 Sided Scan Yes Scanning
Area Width up to 216mm, Length up to 5994mmScanner Grey Scale256 levels
Scan to Keys Scan To: Email Client/ OCR/ Image/ File/ FTP/ Network
Scanner CompatibilityWindows8/8.1/ Windows7/ XP/ Vista
Mac OSX 10.8 or greater
Linux RedHat9 / Ubuntu6.06 / Ubuntu / Fedora / OpenSUSE / Mandriva /
DebianTwain CompliantTwain 2.2 / ISIS and WIA for Windows8/8.1 /
Windows7/ XP / Vista
Twain 2.2 / ICA for Mac OSX 10.8 or greater (Download)
Sane for Linux (Download)Scanner Driver FunctionsTwain Windows and Mac:
ADF Auto Deskew, ADF Auto Deskew, Auto Crop, Blank Page Skip, Base Color
Removal, 2 in 1 Scan, 1 to 2 Scan, Automatic Image Rotation, Color
Dropout, Punch hole removal, Barcode Detection Scanner Warm Up Time0
Second sISIS Yes
Software
Software Included Windows: Button Manager V2/ DS Capture/OmniPage SE 18/ QuickScan Pro Trial
Mac: DS Capture/ Page Manager 9 (Web download only)Kofax VRSYes (Windows)
Connectivity
Interface USB 3.0 @ Superspeed, USB 2.0 @ Hi-Speed Network Interface Wired NA Network Interface Wireless NA
Networking
Wireless Mode NA
Options
Optional Other Seperation Pad for ADF, Pickup Roller for ADF, Reverse
Roller for ADF, Carrier Sheet for Receipt Application, Plastic Card
Carrier Sheet
Weight and Measures
Size316(W) x 187(D) x 183(H)mmWeight4.7 Kg
Environment
Energy Star Compliant Yes Ver 2.0Power Consumption Peak: 59W Or less
Ready: 19W Or less
Sleep: 1.6W or less Noise Level47dBSleep Mode Yes
Others
Warranty12 Months Return To Base
Carton ContentsPDS-6000, Quick Setup Guide, User's Guide, DVD (Windows), AC Adaptor, Power Cord, USB 3.0 cable
What's in the box?
PDS-6000, Quick Setup Guide, User's Guide, DVD (Windows), AC Adaptor, Power Cord, USB 3.0 cable
Product Specifications
Up to Scan Speed 80ppm
Up to Optical Res 600 x 600 dpi
512MB Standard Memory
100 Sheet ADF Capacity
256 Levels Grey Scale
USB 2.0 & USB 3.0 Interface
One Year Return to Base Warranty
