Product Description
Type A3 Desktop Type Sheet Fed Scanner
Scanning sensor unit CIS
Optical resolution 600dpi
Light source RGB LED
Scanning side Simplex, Duplex, Skip blank pages
Interface USB 3.1
Dimensions (W x D x H)
Tray Closed : 480 (W) x 569 (D) x 315 (H)mm
Tray Open : 480 (W) x 723 (D) x 390 (H)mm
Weight Appox. 25.0kg
Power requirements AC 220-240V (50/60Hz)
Power Consumption
Scanning: 66.5 W
Sleep mode: 3.5 W or less
Operating Environment 10 - 35°C (50 - 95°F), Humidity: 20 - 80% RH
Noise 54 dB
Environmental compliance EPEAT Gold certified
Scanning specifications
Black and White
100ppm/200ipm (A4, Landscape, 200dpi/300dpi)
Colour 100ppm/200ipm (A4, Landscape, 200dpi/300dpi)
Output resolution
150 x 150dpi, 200 x 200dpi, 240 x 240dpi,
300 x 300dpi, 400 x 400dpi, 600 x 600dpi
Output mode
Detect Automatically,
Black and White, Error Diffusion,
Active Threshold, Advanced Text Enhancement,
Advanced Text Enhancement II,
256-level Grayscale, 24-bit Colour
Suggested Daily Duty Cycle 30,000 scans/day
Document specifications
Width 50.8 - 305 mm
Length 70 - 432 mm
Thickness
Continuous Feeding: 20 - 209g/m2, 0.04 - 0.25 mm
Non-Separation Mode: 20 - 255g/m2, 0.04 - 0.03 mm
Long document mode Up to 3000mm
Paper separation
Retard Roller and Pre-separation method
Feeder capacity 300 sheets
Special Features
Others
Barcode Recognition, 2D Code, Patch Code, Job Function, Ultrasonic Double-Feed Detection, Staple Detection, Dropout and Color Enhancement, Auto Page Size Detection, 3-D Color Correction, Image Rotation, Skip Blank Page, Edge Emphasis, Moiré Removal,
Prevent Bleed Through / Remove Background, Contrast Adjustment, Shading Correction, Brightness Adjustment, Deskew, Border Removal, Scanning Side Selection, Scan Area Settings, Addon Settings, Text Orientation Recognition, Punch Hole
Removal, Folio Scan, Unnecessary dots removal, Notch removal, Background Smoothing, Character Emphasis, Rapid Recovery System, MultiStreamTM
Bundled Software
Windows
ISIS Driver, TWAIN Driver (32/64bit), WIA Driver, Kofax VRS Driver
CaptureOnTouch Pro
Driver Setting Tool
Consumables
Exchange Roller Kit
Separation Pad
Ink Cartridges (Red, Blue)
Options
Imprinter Unit
Flatbed Scanner Unit 102
Flatbed Scanner Unit 201
White Platen Roller
Product Specifications
Up to 200 images per minute
Up to Optical Res 600 dpi
300 Sheet ADF
RGB LED Light Source
30K Pages Daily Volume
USB & Network Interface
Windows Compatible
