Product Description
Canon’s imageFORMULA DR-G2110 will transform the way your people work and deliver massive savings in time and money. This high end A3 scanner digitises documents with the greatest accuracy and clarity with effective workflow set up for easy retrieval.
Type A3 Desktop Type Sheet Fed Scanner
Scanning sensor unit CIS
Optical resolution 600dpi
Light source RGB LED
Scanning side Simplex, Duplex, Skip blank pages
Interface USB 3.1/ Wired LAN
Dimensions (W x D x H)
Tray Closed : 480 (W) x 569 (D) x 315 (H)mm
Tray Open : 480 (W) x 723 (D) x 390 (H)mm
Weight Appox. 25.0kg
Power requirements AC 220-240V (50/60Hz)
Power Consumption Scanning: 66.5 W
Sleep mode: 3.5 W or less
Operating Environment 10 - 35°C (50 - 95°F), Humidity: 20 - 80% RH
Noise 54 dB
Environmental compliance
EPEAT Gold certified
Scanning specifications
Black and White 120ppm/240ipm (A4, Landscape, 200dpi/300dpi)
Colour 120ppm/240ipm (A4, Landscape, 200dpi/300dpi)
Output resolution
150 x 150dpi, 200 x 200dpi, 240 x 240dpi,
300 x 300dpi, 400 x 400dpi, 600 x 600dpi
Output mode
Detect Automatically,
Black and White, Error Diffusion,
Active Threshold, Advanced Text Enhancement,
Advanced Text Enhancement II, 256-level Grayscale, 24-bit Colour
Suggested Daily Duty Cycle 50,000 scans/day
Document specifications
Width 50.8 - 305 mm
Length 70 - 432 mm
Thickness
Continuous Feeding: 20 - 209g/m2, 0.04 - 0.25 mm
Non-Separation Mode: 20 - 255g/m2, 0.04 - 0.03 mm
Long document mode
5,588mm max
Paper separation
Retard Roller and Pre-separation method
Feeder capacity 500 sheets
Special Features
Others
Barcode Recognition, 2D Code, Patch Code, Job Function, Ultrasonic Double-Feed Detection, Staple Detection, Dropout and Color Enhancement, Auto Page Size Detection, 3-D Color Correction, Image Rotation, Skip Blank Page, Edge Emphasis, Moiré Removal,
Prevent Bleed Through / Remove Background, Contrast Adjustment, Shading Correction, Brightness Adjustment, Deskew, Border Removal, Scanning Side Selection, Scan Area Settings, Addon Settings, Text Orientation Recognition, Punch Hole
Removal, Folio Scan, Unnecessary dots removal, Notch removal, Background Smoothing, Character Emphasis, Rapid Recovery System, MultiStreamTM
Bundled Software
Windows
ISIS Driver, TWAIN Driver (32/64bit), WIA Driver, Kofax VRS Driver
CaptureOnTouch Pro
Driver Setting Tool
Consumables
Exchange Roller Kit
Separation Pad
Ink Cartridges (Red, Blue)
Options
Imprinter Unit
Flatbed Scanner Unit 102
Flatbed Scanner Unit 201
White Platen Roller
What's in the box?
Main DR-G2110 Unit
USB Cable
Power Cable
Setup DVD
Reference Guide
Cleaning Cloth
Packing Materials
Product Specifications
110ppm Simplex & 220ipm Duplex
Optical Resolution 600 dpi
500 Sheet ADF Capacity
50K Sheet Daily Duty Cycle
RGB LED Light Source
USB & Network Interface
CIS Scanning sensor unit
Brochure for Canon imageFORMULA DR-G2110 A3 Document Scanner
