Brief Overview
DS-70000, DUPLEX 70PPM, HIGH VOLUME A3 SCANNER 200 SHEET ADF & FLATBED
Product Description
Epson WorkForce DS-70000, A3 Flatbed Document Scanner B11B204345
High speed, large format scanner for business productivity. Scan documents as large as 297 x 2540mm down to 68 x 119mm via ADF or 297mm x 431mm on the scanner bed. Ultra-fast scanning speeds of 70 ppm/140ipm. Built-in 200-sheet Automatic Document Feeder, automatic duplex scanning, ultrasonic double-feed detection.
Specifications :
Scanner Type : A3 Flatbed document scanner
Optical Resolution : Upto 600 dpi
Automatic Document Feeder (ADF) : One-Pass Duplex
Supported Format : A3, B4, A4, B5, A5, B6, A6, Legal, Letter, Ledger, Executive, Check
Pixel Depth Levels : Grey : 16 bit in, 8bit out
Colour: 48bit in, 24bit out
Photo Electric Device : 4 lines colour CCD
Light Source : Ready Scan LED technology
Output Resolution : 50-4800dpi, 7200dpi, 9600dpi
LCD Display : Epson Network Interface Panel (Option)
ADF Min Document Size (mm) : 68mm x 120mm
ADF Max Document Size (mm): 297mm x 2,540mm
Scanning Speed A4 (200/300dpi) : 70ppm / 140ipm
Scanning Speed A4 Colour (200/300dpi) : 70ppm / 140ipm
Scanning Speed A4 Line Art (200/300dpi) : 70ppm / 140ipm
Supported File Format : PDF, Searchable PDF, PDF/A, Secured PDF, JPEG, BMP, TIFF, Multi-TIFF
File Compression Method : Hardware JPEG compression, TIFF Compression (JPEG(7) , CITT G4, LZW) , PDF Compression
Advanced Imaging Features : Auto rotation (Windows only), Automatic De-Skew, Skip blank page, Automatic Multi-Document Recognition, Automatic B/W or colour detection, Manual / Automatic Job Separation, Automatic Folder Creation, Horizontal & Vertical Document Split, Book spine correction, RGB colour Dropout, RGB colour Enhance, Dual Image Output (Windows only),Punch hole Removal, Auto Area Segmentation (AAS), Pre-defined scanning settings (Windows only), Text Enhancement, Edge Fill, Advanced cropping feature for Auto size (Windows only), Unsharp Mask (USM), Descreening, Barcode Recognition, Zonal OCR A & B
Advanced Document Integration : Scan to email, FTP, SharePoint, Web folders, network folders, Print
Paper Handling
ADF Paper Setting Capacity : 200 Pages
ADF Paper Weight : 35g/m2 ~ 128g/m2
ADF Media Types : Paper (laser, inkjet), Normal Paper, Recycling paper
Daily Duty Cycle : 8,000 pages / day
USB Interface : High Speed USB 2.0
Network Interface Panel : Option
Ethernet Settings : 10BASE-T, 100BASE-TX, 1000BASE-T, Full duplex, Half duplex
Panel Type : 5-line LCD with Push Scan features
Protocols Supported : TCP/IP, DHCP, DNS, HTTP, SNMP, SLP
IPv6 Support : Yes
Push Scan Features : Yes (Document Capture Pro/Server)
User Authentication :Yes (Document Capture Pro)
OS : Windows XP, x64, Vista, x64, Windows 7, x64, Windows Server 2003, 2003 R2 , 2008 , 2008 R2
Terminal Service, Presentation Server 4.5, XenApp 5.0, XenApp 6.0
Mac OS 10.4.11 or later
Consumables (Option) : Roller Assembly Kit (B12B813501)
Warranty : Standard 1 Year Onsite Warranty
Optional Extended Warranty :Additional 2 Years Onsite 3YWDS70000
Dimensions (W x D x H): 640 x 522 x 289mm
Weight : Approx. 26.9 kgs
What's in the box?
Product Specifications
Up to 70ppm in A4
Up to Resolution 600 dpi
200 Pages ADF Capacity
8K Pages Daily Duty Cycle
4 Line Colour CCD
USB 2.0 & Ethernet 10/100
One Year on Site Warranty
Brochure for Epson DS-70000 A3 Document Scanner
