Brief Overview
WORKFORCE DS-560 A4 WIRELESS DOCUMENT SCANNER
Product Description
The Epson WorkForce DS-560 is a wireless document scanner designed for a
variety of demanding organisations and sectors, such as government,
bank, healthcare and small business.
Epson WorkForce DS-560 B11B221501
SCANNER TYPE Sheet Feed, one pass duplex A4 colour scanner
OPTICAL RESOLUTION 600 x 600 dpi
OUTPUT RESOLUTION 75 to 1200 dpi
EFFECTIVE PIXELS 5,100 x 21,600 pixels
COLOUR SCAN MODE
(Output bit depth) 48-bit internal / 24-bit external
GREYSCALE SCAN MODE
(Output bit depth) 16-bit internal / 8-bit external
MONOCHROME 1-bit
PHOTOELECTRIC DEVICE 1 line CMOS Contact Image Sensor
LIGHT SOURCE Three Colour RGB LED
MAXIMUM EFFECTIVE SCAN AREA
DOCUMENT SIZE Plastic card (in portrait scanning only),
A4, A5, A6, B5, Business card, Letter,
Legal and Custom sizes (can set for up to 5 different paper types),
A3 size supported by digital stitching
Max. size: 216 x 914.4 mm
Min. size: 53.5 x 73.7 mm
INPUT TRAY CAPACITY 50 sheets (Based on 75g/m2 paper)
PAPER WEIGHT 50-209 g/m2
SCANNING SPEED
(A4/Letter Size) 26ppm/52ipm : 200dpi – Black & White, Colour, Grey
26ppm/52ipm : 300dpi – Black & White, Colour, Grey
18ppm/36ipm : 400dpi – Black & White, Grey
5ppm/10ipm : 400dpi Colour
18ppm/36ipm : 600dpi Black & White, Grey
5ppm/10ipm : 600 dpi Colour
FUNCTIONS
DOCUMENT ENHANCEMENT TOOLS 30 user-definable scan job settings
Double-Feed Detection
Text Enhancement
Auto Area Segmentation
Colour Enhance
Colour Dropout
Skip Blank Page
Searchable PDF (Windows only)
Encrypted PDF
BUNDLED SOFTWARE Epson® Scan
EMC Captiva ISIS (Windows only, via web download)
ABBYY® FineReader® OCR
Document Capture Pro
NewSoft™ Presto!® BizCard OCR (Windows on CD, Mac via web download)
TWAIN and ISIS drivers
SUPPORTED PLATFORMS
USB1.1
USB2.0 High-Speed Microsoft® Windows® 2000 Professional/ XP (Home Edition/ Professional/ Professional X64)/ Windows Vista®
Mac OS® X 10.3.9 or later
(Please Note: ABBYY FineReader Sprint Plus 6 is not compatible with Mac 10.7 & 10.8)
INTERFACE WiFi / USB2.0 (Type-B standard connector) x 1++
ENVIRONMENTAL CONDITIONS
TEMPERATURE 5°C to 35°C (operating)
HUMIDITY 10% to 80% without condensation (operating)
What's in the box?
Epson WorkForce DS-560, Setup Sheet, Warranty / Registration Card, USB Cable, Software CD-ROM, AC Adapter & Cable
Product Specifications
Up to Print Speed 26ppm/52ipm
Up to Optical Res 600 x 600 dpi
Three Colour RGB LED
Contact Image Sensor
50 Sheet ADF
USB 2.0 & Wireless Interface
One Year Return to Base Warranty
Brochure for Epson WorkForce DS-560 A4 Document Scanner
