Brief Overview
Fujitsu fi-7240 - Document scanner - Duplex - 600 dpi x 600 dpi - up to 40 ppm (mono) / up to 40 ppm (colour) - ADF ( 80 sheets ) - USB 2.0
Product Description
The new scanners allow the user to scan a wide variety of paper thicknesses (27 to 413 g/㎡), as well as plastic cards with the same feeding mechanism inherited from our high-end models. In addition, Paper Protection constantly checks along the whole document length during scanning and automatically stops paper feeding when error occurs to avoid any damage to the document. All in all these deliver the reliable scanning experience expected from Fujitsu.
Specifications
Description fi-7240
Supported operating systems Windows® 10 (32-bit/64-bit), Windows® 8/8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Vista® (32-bit/64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit), Windows Server® 2008 (32-bit/64-bit), Linux (Ubuntu 16.04 / 14.04 LTS)
Sensor type Flatbed (FB) and Automatic Document Feeder (ADF)
Scanning modes Simplex / Duplex, Color / Grayscale / Monochrome
Image sensor type Color CCD (Charge-coupled device) x 3 (front x 1, back x 1, flatbed x 1)
Light source White LED Array x 3 (front x 1, back x 1, flatbed x 1)
Multifeed detection Ultrasonic multi-feed detection sensor x 1, Paper detection sensor
Document size Maximum 216 x 355.6 mm (8.5 x 14 in.)
Minimum(1) 50.8 x 54 mm (2 x 2.13 in.) (Landscape / Portrait)
Long paper scanning(2) 216 x 5,588 mm (8.5 x 220 in.)
Paper weight(3)
(Thickness) Paper 27 to 413 g/m² (7.2 to 112 lb.)
*A8 size: 127 to 209 g/m² (34 to 56 lb.)
Plastic Card 1.4 mm or less(4)
Scanning speed(5)
(A4, Portrait) Color(6) Simplex: 40 ppm, Duplex: 80 ipm
(200 / 300 dpi)
Grayscale(6)
Monochrome(7)
Paper chute capacity
(A4 Landscape)(8) 80 Sheets ( A4: 80 g/m² or 20 lb. )
Background colors White / Black (Selectable)
Optical resolution 600 dpi
Output resolution(9) Color (24-bit) 50 to 600 dpi
(adjustable by 1 dpi increments), 1200 dpi (driver)(10)
Grayscale (8-bit)
Monochrome (1-bit)
Output format Color 24-bit
Grayscale 8-bit
Monochrome 1-bit
Internal video processing 1,024 levels (10-bit)
Interface USB 2.0 / USB 1.1
Connector shape B type
Image processing functions Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Halftone, De-Screen, Emphasis, Color cleanup, Dropout color (None / Red / Green / Blue / Saturation), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Automatic page size detection
Power requirements AC 100 to 240 V ±10%
Power consumption Operating: 39 W or less
Sleep mode: 1.8 W or less
Auto standby (OFF) mode: 0.35 W or less
Operating environment Temperature: 5 to 35 °C (41 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing)
Dimensions: Width x Depth x Height(11) 300 x 577 x 234 mm (11.81 x 22.72 x 9.21 in.)
Weight 8.8 kg (19.4 lb)
Included software / drivers PaperStream IP (TWAIN/TWAIN x64/ISIS), Software Operation Panel, Error Recovery Guide, PaperStream Capture, ScanSnap Manager for fi Series(12), Scan to Microsoft SharePoint(12), ABBYY FineReader for ScanSnap™(12), Scanner Central Admin Agent
Environmental compliance ENERGY STAR® / RoHS
Included items ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
What's in the box?
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
Product Specifications
40ppm Simplex & 80ipm Duplex
Up to Optical Resolution 600 dpi
80 Sheets ADF Capacity
4K Sheet Daily Duty Cycle
White LED Array x3 Light Source
USB 2.0 Interface
One Year Return to Base Warranty
Brochure for Fujitsu Image FI-7240 A4 Document Scanner
