Brief Overview
NETWORK SCANNER, 25PPM (50 IPM), A4, DUPLEX,NET,8.4IN TSCRN 1YR RTB WTY
Product Description
The analysts at Keypoint Intelligence were impressed with how easy it was to capture, process, and deliver paper-based information using the ScanSnap N7100 network scanner. “Users can create custom preconfigured scan profiles to streamline frequently recurring scan chores, and personalize the ScanSnap N7100’s interface so that it displays features and functionalities they use the most,” noted Bsales.
Specifications
Description N7100
Scanner type ADF (Automatic Document Feeder), Duplex scanning
Scanning modes Color, grayscale, monochrome, automatic (color / grayscale / monochrome detection)
Image sensor type Color CIS x 2 (front x 1, back x 1)
Light source 3 Color LED (Red / Green / Blue)
Multi-feed detection Supported (Standard) ultrasonic multi-feed defection sensor
Document
size
(1) Normal mode
without
Carrier Sheet A4, A5, A6, B5, B6, Business card, Post card, Letter, Legal and Custom sizes (Max: 216 x 355.6 mm (8.5 x 14.17 in.), Min: 50.8 x 50.8 mm (2 x2 in.)) Automatically recognizes document size
Normal mode
with
Carrier Sheet Use of a Carrier Sheet permits the scanning of A3, B4, 11 x 17 in., and photographs as well as the documents sizes that are listed above
Long paper
scanning(Maximum) 3,048 mm (120 in.) (2)
Paper weight
(Thickness) 40 to 209 g/㎡ , or 11 to 56 lb (paper thickness 0.049 to 0.257 mm)
A8 size: 127 to 209 g/㎡ , 34 to 56 lb (paper thickness 0.157 to 0.257 mm)
Cards* can be used. (thickness 0.76 mm or less)
Embossed cards*: useable
* Landscape only
Scanning
speed
(A4 Portrait)(3) Color Simplex: 25 ppm (200, 300 dpi)
Duplex: 50 ipm (200, 300 dpi)
Grayscale
Monochrome
Paper chute capacity 50 sheets (Letter/A4, 80 g/㎡ or 20 lb) (Active loadable ADF)
Expected daily volume 2,000 Pages
Optical resolution
600 dpi
Output
resolution(4) Color (24-bit) 150 / 200 / 300 / 600 dpi
Grayscale (8-bit)
Monochrome (1-bit)
Output methods(5)
Save image data to network folder/FTP server
Send image data by E-mail
Print (Sends image data to printer server)
Send image data by FAX (Sends image data to FAX server in E-mail format)
Save image data to SharePoint portal server
Output file formats PDF(Searchable / Password-protected / compressed / Marker Index processed), JPEG, TIFF(single / multi-page), page output in reverse order
Authentication (5)
User authentication:
Active Directory or Open LDAP(for Solaris or Linux), Standalone authentication (6)
Folder authentication
Active Directory or Open LDAP(for Solaris or Linux)
Network interface 10BASE-T, 100BASE-TX, 1000 BASE-T
Network protocols TCP/IP(IPv4 / IPv6 (7) ), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Scanner Central Admin Server Windows® 2003, 2008, 2008 R2, 2012, 2012 R2, 2016 Server required
Network Server Authentication Windows® 2003, 2003 R2, 2008, 2008 R2, 2012, 2012 R2, 2016 Server or open LDAP
Power requirements AC 100 to 240 V ±10%
Power consumption Operating mode: 38 W or less
Sleep mode: 2.0 W or less
Auto Standby (off) mode: 1.0 W or less
Operating environment Temperature: 5 to 35°C (41 to 95°F)
Relative humidity: 20 to 80% (Non-condensing)
Dimensions:Width X Depth X Height (8) 300 x 232 x 172 mm (11.8 x 9.1 x 6.8 in.)
Weight 6 kg or less (28.7 lb)
Environmental compatibility ENERGY STAR® / RoHS
Display LCD 8.4 inch XGA (1,024 x 768 pixels) TFT Color monitor
Touch panel Analog resistive touch panel
Keyboard Software keyboard
Product Specifications
25ppm Simplex & 50ipm Duplex
Up to Optical Resolution 600 dpi
50 Sheets ADF Capacity
3 Color LED RED/Green/Blue
2K Pages Scan Daily Volume
USB & Network Interface
One Year Limited Warranty
Brochure for Fujitsu ScanSnap N7100 A4 Document Scanner
