Brief Overview
SCANJET ENTERPRISE FLOW 5000 S4 SHEET FEED SCANNER / 50 PPM 100
IPM / UP TO 600 DPI / RDDC 6000 PAGES / ADF CAPACITY 80 SHEETS / USB /
ADF SINGLE PASS DUPLEX
Product Description
Technical specifications
Scanner type Sheetfed
Scan resolution, optical Up to 600 dpi (colour and monochrome, sheet-feed)
Duty cycle (daily) Recommended for 6000 pages per day
Bit depth 24-bits external/48-bits internal
Levels of grayscale 256
Task speed 10 x 15 cm colour photo to file (200 dpi, 24-bit, tiff): about 5.18 sec for single image scan
10 x 15 cm colour photo to email (150 dpi, 24-bit): about 4.98 sec for
single image scan, about 1.43 sec for single image send to email,
totally 6.41 sec
A4 PDF to email (300 dpi, 24-bit): about 6.63 sec for single image scan,
about 3 sec for single image send to email, totally 9.63 sec
Media types Cut sheet paper, printed paper (laser and ink), pre-punched
paper, bank checks, business cards, freight bills, carbonless forms,
plastic carrier sheets for easily damaged documents, previously stapled
media with staple removed
Media weights, supported ADF 40 to 413 g/m²
Scan file format For text & images: ePub 3.0, HTML 4.0, Excel file
format (*.xls, *.xlsx), PowerPoint file format (*.pptx), Word (*.docx),
WordPerfect (*.wpd), searchable PDF, JPEG, PNG, BMP, TIFF, Text (.txt),
Rich Text (rtf), XML and XPS
Scan input modes Two scan modes (simplex/duplex) on front-panel for HP
SDSS in Win OS and third parties applications via TWAIN, ISIS and WIA
Scanner advanced features Auto colour detect; Auto crop; Auto exposure;
Auto orientation; OCR; Edge removal; Background cleanup; Remove hole;
Colour drop out; Straighten the page; Scan to cloud; Scan to email; PDF
security; Misfeed detection advance setting; Batch processing; Barcode;
Scan to multiple destinations
Control panel 2-line 16 character per line LCD display, Simplex button,
Duplex button, Cancel button, Power button with a LED and Tool button
ADF specifications Automatic document feeder capacity 80 sheets
Automatic document feeder speed Up to 50 ppm/100 ipm (black & white, 300ppi) 3
Scan size (ADF), maximum 216 x 3100 mm
Scan size (ADF), minimum 50.8 x 50.8 mm
Compatible operating systems Compatible operating systems
Compatible operating systems Microsoft® Windows® 10, 8.1, 8, 7: 32-bit/64-bit
Mac compatible No
Connectivity Connectivity, standard
Hi-Speed USB 2.0 and USB 3.0
Connectivity, optional USB 2.0 port for Wi-Fi accessory
Twain version TWAIN version 2.1
Power and operating requirements
Voltage Input Voltage: 90 to 264 VAC, 50/60 Hz
Power consumption 4.4 watts (ready), 0.8 watts (sleep), 0.1 watts (off), 0.1 watts (auto-off) 2
Operating temperature range 10 to 35ºC
Operating humidity range 15 to 80% RH (non-condensing)
Dimensions and weight Minimum dimensions (W x D x H) 310 x 198 x 190 mm
Weight 3.8 kg
What's included
Warranty One-year bench commercial warranty whole unit replacement,
phone and Web support included. Warranty may vary by country as required
by law. Go to http://www.hp.com/support to learn about HP service and
support options in your region.
What's in the box
HP ScanJet Enterprise Flow 5000 s4 Sheet-feed Scanner
Installation guide
Support flyer
Warranty guide
2 CDs
Power cord
USB cable
Power adapter
Software included
HP WIA Scan Driver
HP TWAIN Scan Driver
HP Smart Document Scan Software
HP Scanner Tools Utility
I.R.I.S. Readiris Pro OCR
I.R.I.S. Cardiris
Nuance PaperPort
EMC ISIS driver
Cable included
Yes, 1 USB cable
What's in the box?
HP ScanJet Enterprise Flow 5000 s4 Sheet-feed Scanner
Installation guide
Support flyer
Warranty guide
2 CDs
Power cord
USB cable
Power adapter
Product Specifications
Up to Scan Speed 50ppm/100ipm
Up to Optical Resolution 600 dpi
80 Sheets ADF
48-bit Colour Depth
6000 Pages Daily Duty Cycle
USB 2.0 Interface
One Year Return tom Base Warranty
