Brief Overview
A3,600dpi,ADF,200sht,USB2.0,WIN,12MTH WARRANTY
Improve productivity with rapid speeds and customizable features. Easily integrate this 11 x 17 flatbed scanner into your office. Scan with confidence at up to 50 ppm/100 ipm.1 Put big jobs in the 200-page automatic document feeder for accurate results.
Product Description
Specifications
Bit Depth 48-bit
Dimensions (WxHxD) 692mm x 338mm x 558mm
Imaging Technology
Interface 1 Hi-Speed USB 2.0
Model L2683A
Paper Handling Standard, 200 sheets, Paper (plain, inkjet, photo), envelopes, cards (index, greeting), 3-D objects
Performance
Resolution Up to 600 dpi
Software
Warranty 1 Year
Weight 37 kg
functions 11.7 x 17 in, Flatbed, ADF, 48-bit, Up to 600 dpi, Scan to
folder, scan to email, scan to copy, scan to application, HP Smart
Document Scan Software, EMC ISIS/TWAIN drivers, Kofax VirtualRescan
(VRS) Professional, I.R.I.S. Readiris Pro OCR, WIA drivers, HP Web
Jetadmin SNMP Proxy Agent, 11.7 x 34 in, None
Misc None
Automatic document feeder speed Up to 50 ppm/100 ipm (b&w, gray, color, 200 dpi)
Button functions 2 quick start buttons (Scan, Copy), Cancel, Tools, Powersave
Cable included Yes, 1 Hi-Speed USB 2.0
Compatible Operating System PC: Windows 8 (32-bit, 64-bit), Windows 7
(32-bit, 64-bit), Windows Vista (32-bit, 64-bit): 2 GHz processor
(recommend Intel Core 2, 2 GHz, Duo Processor or equivalent); 2 GB RAM;
150 MB for TWAIN and ISIS drivers; USB 2.0; 1024 x 768 SVGA monitor;
Windows XP, Service Pack 3: 1.6 GHz processor; 1 GB RAM; 150 MB for
TWAIN and ISIS drivers; USB 2.0; 1024 x 768 SVGA monitor; Windows 2000:
1.3 GHz processor, 512 MB RAM
Daily duty cycle Recommended daily duty cycle: 5000 pages
Energy Star Qualified Yes
Levels of grayscale 256
Media weights, recommended 13 to 32 lb
Multifeed detection Yes, ultrasonic
Operating humidity 15 to 80% RH
Operating temperature range 50 to 95 F, 50 to 95 F (10 to 35 C)
Photo automatic document feeder capacity None
Power consumption 112 watts maximum
Preview scan speed Up to 4 sec
Scan file format PDF (image-only, searchable, MRC, PDF/A, encrypted),
TIFF (single page, multi-page, compressed: G3, G4, LZW, JPEG), DOC, RTF,
WPD, XLS, TXT, XML, XPS, HTML, OPF, JPG, BMP, PNG
Storage humidity 15 to 80% RH
Transparency adapter No
Twain version Version 2.1
What's in the box HP Scanjet N9120 Document Flatbed Scanner; Hi-Speed
USB 2.0 cable; power cord; CD-ROMs with software (HP Smart Document Scan
Software, Kofax VirtualRescan (VRS) Professional, IRIS Readiris Pro
OCR, EMC ISIS/TWAIN drivers, WIA drivers); Printed Setup and Support
Guide
What's in the box?
HP Scanjet N9120 Document Flatbed Scanner; Hi-Speed USB 2.0 cable; power
cord; CD-ROMs with software (HP Smart Document Scan Software, Kofax
VirtualRescan (VRS) Professional, IRIS Readiris Pro OCR, EMC ISIS/TWAIN
drivers, WIA drivers); Printed Setup and Support Guide
Product Specifications
Up to Scan Speed 50ppm/100ipm
Up to Resolution 600 x 600 dpi
200 Sheet ADF
48 Bit Depth
5000 Pages Per Day
USB 2.0 Interface
One Year Return to Base Warranty
Brochure for HP Scanjet N9120 A3 Document Flatbed Scanner
