Product Description
The ultimate A3 scanning hub - flatbed, 150-sheet ADF, and 70ppm/140ipm power. Handles up to 11,200 pages daily for secure, high-capacity enterprise workflows with versatile Open Platform integration.
Seamless Connectivity & Control
Centralised control, Wi-Fi, USB, and Ethernet connectivity, plus a user-friendly touch panel ensure fast, high-output, reliable scanning.
Leading-Edge Image Processing
State-of-the-art imaging, glass dirt detection, punch hole correction & auto colour/gray/monochrome detection ensure accuracy.
Enterprise-Grade Reliability
High-volume scanning up to 11,200 pages daily with document protection and error prevention ensures lasting, reliable performance.
Forward-Thinking Sustainability
Enterprise responsible with eco-friendly materials and future-ready design: sustainable solutions for evolving business needs.
Specifications:-
General
Power consumption 26
Power consumption -(economy) 7.6
Power consumption -(standby) 0.7
Product Dimensions 555 x 604 x 257 mm (Width x Depth x Height)
Product weight 19.7 kg
Supply Voltage 220 V - 240 V
Supported Humidity - Operation (from) 15 %
Supported Humidity - Operation (to) 80 %
Supported Humidity - Storage (from) 15 %
Supported Humidity - Storage (to) 85 %
Supported Temperature - Operation (from) 5
Supported Temperature - Operation (to) 35
Supported Temperature - Storage (from) -25 °C
Supported Temperature - Storage (to) 60 °C
Technology
ADF Maximum Document Size (Horizontal) 297
ADF Maximum Document Size (Vertical) 3556
Optical Resolution ADF - Horizontal 600
Optical Resolution ADF - Vertical 600
Optical Resolution 2 -(Horizontal) 600
Optical Resolution 2 -( Vertical) 600
Scanner Type Flatbed Scanner
Scanning Colour Depth - Input (Colour) 30 Bits Color
Scanning Colour Depth - Input (Mono) 10 Bits Monochorme
Scanning Colour Depth - Output (Colour) 24 Bits Color
Scanning Colour Depth - Output (Mono) 8 Bits Monochorme
Ultrasonic Sensor Yes
Paper / Media Handling
Automatic Document Feed - No Yes
Automatic Document Feed - Capacity 150 Pages
Automatic Document Feeder Type Single pass dual scanning
Document size - Flatbed A3
Duplex (Scanning) Yes
Paper Formats A3 (29.7x42.0 cm), A4 (21.0x29.7 cm), A5 (14.8x21.0 cm), A6 (10.5x14.8 cm), Legal, B4, B5, B6
Paper weight Auto loading (From) 52
Paper weight Auto loading (To) 128
Reliability Daily Duty Cycle 11200 Pages
Connectivity
Compatible Operating Systems Windows 11 or later, MAC OS 10.15 + or later, Linux
Connectivity USB 3.2 Gen 1x1, Wi-Fi Direct, USB host, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Wireless LAN
Ethernet settings 10BASE-T / 100BASE-TX / 1000BASE-T / Full-duplex / Half-duplex
Included Software Document Capture Pro
Panel type Touchscreen
Push scan features Yes, (with Document Capture Pro solutions)
Advanced Features
3D 26
Other Features
Panel Display Type Colour
Panel (Diagonal size) 10.9 cm
Scan
Advanced document integration Scan to Email, Scan to FTP, Scan to Microsoft SharePoint®, Scan to Network folders, Scan to USB, Computer (Epson Document Capture Pro)
Light Source (Scanner) ReadyScan LED technology
Output formats JPEG
Scanning Features
Scanner features Skip blank page
File compression features Hardware JPEG compression
