Product Description
Efficiency at new heights with evolved feeding
The fi-8270 offers an innovative and superior experience, and comes with versatile scanning as flatbed and ADF. It provides quick scans in just 1.7 seconds ipm (200/300 dpi) as flatbed, and 70 ppm/140 ipm (200/300 dpi, color, A4 portrait) as ADF. The scanner loads up to 100 sheets at a time, and comes equipped with a capability of scanning up to as many as 10,000 sheets a day.
Versatile scanning with both flatbed and ADF
Scans big volumes with “Automatic Separation Control”
"Paper Protection" function using Image Monitoring technology and sound technology
Optimized high-quality image data with "PFU Clear Image Capture"
Scans variety of documents including passports and booklets
Color LCD Panel for easy operation
PaperStream IP and PaperStream Capture providing advanced image processing functions, with PaperStream Capture Pro software as a premium option
PaperStream ClickScan for ad-hoc use
Specifications
Product Name fi-8270
Scanner Type ADF (Automatic Document Feeder) / Manual Feed / Flatbed, Duplex
Scanning Speed*1 (A4 Portrait) (Color*2/Grayscale*2/Monochrome*3)
ADF Simplex: 70 ppm (200/300 dpi)
Duplex: 140 ipm (200/300 dpi)
Flatbed 1.7 seconds (200/300 dpi)
Image Sensor Type
ADF: CIS x 2 (front x 1, back x 1)
Flatbed: Color CCD X 1
Light Source
ADF: RGB LED x 2 (front x 1, back x 1)
Flatbed: White LED
Optical Resolution 600 dpi
Output Resolution*4 (Color / Grayscale / Monochrome) 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)*5
Output Format Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
Background Colors
ADF: White / Black (selectable)
Flatbed: White (or optional black)
Document Size (ADF)
Maximum*6 215.9 x 355.6 mm (8.5 x 14 in.)
Minimum 48 x 50 mm (1.9 x 2 in.)
Long Page Scanning*7 6,096 mm (240 in.)
Document Size (Flatbed) Maximum 215.9 x 297 mm (8.5 x 11.7 in.)
Paper Weight (Thickness) Paper 20 to 465 g/m² (5.3 to 124 lb)*8
Booklet Less than 7 mm (0.276 in.)*9
Plastic Card 1.4 mm (0.055 in.) or less*10
ADF Capacity*11*12 100 sheets (A4 80 g/m² or Letter 20 lb)
Expected Daily Volume*13 10,000 sheets
Multifeed Detection Overlap detection (Ultrasonic sensor), Length detection
Paper Protection Image monitoring, Sound detection (iSOP)*14
Interface
USB USB 3.2 Gen1x1 / USB 2.0 / USB 1.1
Ethernet 10BASE-T, 100BASE-TX, 1000BASE-T
Power Requirements AC 100V - 240V 50/60 Hz
Power Consumption
Operating Mode 28 W or less / 17 W (Eco mode)
Sleep Mode LAN: 2.0 W or less
USB: 1.4 W or less
Auto Standby (Off) Mode 0.2 W or less
Operating Environment
Temperature 5 to 35 °C (41 to 95 °F)
Relative Humidity 15 to 80% (Non-condensing)
Environmental Compliance ENERGY STAR®, RoHS
Dimensions (W x D x H)*15 300 x 577 x 234 mm (11.8 x 22.7 x 9.2 in.)
Weight 8.8 kg (19.4 lb)
Supported Operating System Windows® 11*16, Windows® 10*16, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Linux (Ubuntu)*17
Software / Drivers PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver*18, Image Scanner Driver for Linux (SANE)*18*19, PaperStream Capture, PaperStream ClickScan*19, PaperStream NX Manager, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™*19, Scanner Central Admin Server
Image Processing Functions Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge filler, Vertical streaks reduction, Background pattern removal, Cropping, Static threshold
Included Items ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
