Product Description
Zebra's ZQ500™ Series just got tougher. The premium ZQ511™ and ZQ521™ printers - both available in RFID models - give you best-in-class, rugged mobile printing for applications in any industry. Experience ultimate durability. Engineered for tough, demanding indoor and outdoor conditions, these printers can withstand significant drops, tumbles, accidents, and environmental extremes that are common in mobile workplaces. Additional features, enhanced durability, and military-grade design mean this printer will work as hard as you do.
Tough. Reliable. Built to Endure | The Most Rugged Printers on the Market
You need a mobile printer that can handle serious abuse. Designed and certified to meet MIL-STD 810G for drop and shock, and tumble tested per the IEC68-2-32 spec to handle 1300 tumbles from 3.3' (1M), the ZQ511 and ZQ521 printers can withstand more than the average mobile printer.
Protection from solid and liquid ingress is no problem with an IP54 rating right out of the box without the need for a protective case.
If this isn't enough to convince you that these are ultra-rugged mobile printers, we also offer an optional exoskeleton case that increases our standard drop testing from 6.6' to 10' and improves the IP rating to IP65.
Built to Last
New over-molding helps increase longevity and keeps your ZQ500 Series looking good over the life of the printer.
Print it All: Receipts, RFID tags, Labels, and Linerless
Optimized for on-demand receipt printing in 3" (72mm) and 4" (104mm) print widths, the ZQ511 and ZQ521 printers also print a variety of labels including UHF RFID tags for all your tracking needs. Zebra's comprehensive RFID portfolio is the only one to include mobile printers to help you reduce errors, and print and encode RFID labels on the go.
Features
Android, Apple iOS, and Windows Mobile connectivity
Bluetooth specification 4.1 EDR + LE
WLAN 802.11ac
Fast roaming 802.11r supported
528 MHz ARM processor
3250 mAh PowerPrecision+ (retrievable, rechargeable Li-Ion)
USB On-The-Go ports (with optional strain relief)
Power Smart Print Technology - anticipates upcoming printing to optimize battery consumption and print speed
Direct thermal printing of barcodes, text, and graphics
IP54 rated for protection against solid and liquid ingress
Technical Specs
Memory
Standard Memory 512 MB
Technical Information
Application/Usage Mobile
Barcode Symbology Supported Code 11
UPC-E with 2 or 5 Digit Extension
Code 128
EAN-13
Code 49
Interleaved 2 of 5
Data Matrix
Maxi Code
Codabar (NW-7)
UPC-A
Code 39
PDF417
2D
QR Code
Planet Code
LOGMARS
GS1 DataBar
Plessey
MSI
EAN-8
2 and 5 Digits Add-on
MSI PLESSEY
UCC/EAN 128
ISBT-128
Code 93
Micro PDF-417
Codabar
POSTNET
Codablock
FIM
Standard 2 of 5
Industrial 2 of 5
AZTEC
UPC-E
TLC 39
Maximum Print Width 103.89 mm (4.09")
Recommended Use Label/Receipt Print
Connectivity Technology Wireless
Features Rugged
Drop Resistant
Tear Bar
Dust Resistant
Maximum Mono Print Speed 127 mm/s
Print Color Capability Monochrome
Maximum Print Length 990.60 mm
Real-Time Clock Yes
Maximum Print Resolution (dpi) 203
Power Description
Power Source Battery
Warranty
Limited Warranty 2 Year
Fonts & Emulation
Language Emulation XML
ZPL
CPCL
Miscellaneous
Platform Supported PC
Android
iOS
Environmental Conditions
Storage Relative Humidity 10% - 90%
Storage Temperature -30°C - 66°C
Operating Temperature -20°C - 55°C
Operating Relative Humidity 10% - 90%
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Near Field Communication (NFC) Yes
Physical Characteristics
Weight (Approximate) 784.7 g
Height 66 mm
Width 154.9 mm
Depth 157.5 mm
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ52-BAW000A-00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ521
Product Name ZQ521 Mobile Printer
Product Series ZQ500
Brand Name Zebra
Media Types & Handling
Media Thickness 58.4 µm
Maximum Roll Diameter 56.90 mm
Media Type Tag
Label
Gap
Black Mark
Receipt
Linerless
Media Sensor Black Mark Sensor
Gap Sensor
Maximum Label Width 50.80 mm
What's in the box?
Zebra ZQ521 (ZQ52-BAW000A-00) 4" BT4/WLAN Mobile Label Printer
User Guide
Product Specifications
Mono Print Speed 127mm/sec.
Max. Print Resolution 203 dpi
512MB Standard Memory
528 MHz ARM Processor
CPCL & ZPL & XML Language
USB, Bluetooth & Wireless
2 Years Limited Warranty
