Product Description
Print anywhere, anytime. Equipped with the latest in direct thermal technology, this A4 mobile printing solution is designed to minimise downtime and maximise convenience.
Print anywhere, anytime
At just 26cm wide and weighing approximately 480g (excluding battery), the PJ-863 offers a true A4 mobile solution that fits easily into any work area
Connect your way
With convenient connectivity options available at your fingertips including Bluetooth and USB-C, the PJ-863 can easily adapt to your working environment
High-quality printing
Experience print speeds of up to 13.5ppm* and high quality, 300dpi outputs that ensure your documents are always available quickly and are of professional quality
Seamless integration and setup
With the ability to support printer command languages, including ZPL2 emulation, this mobile printer offers compatibility with a variety of embedded systems
A complete mobile printing solution
Experience a host of optional accessories including USB-C AC adapters, long-lasting Li-ion batteries, paper guides, protective cases and more
Basic Specs
FUNCTIONS Print
PRINTER TYPE Portable printer
PRODUCT DIMENSIONS (WIDTH X DEPTH X HEIGHT) 255 mm x 55 mm x 30 mm
PRINT SPEED Up to 13.5ppm, 3ips fast print speed*
PAPER TYPE
Paper and Synthetic
Full-page: Cut Sheet, Continuous Roll, Perforated Roll, Fan-Folded
Labels: Cut Sheet, Fan-Folded
PAPER SIZE A4, A5, Letter, Legal, and Continuous length
MAXIMUM PAPER CAPACITY Cut paper and Roll paper: 215.9mm, 8.5 inches (Letter, Legal)
WARRANTY 1 year Return to Base Warranty
Print
RESOLUTION 300×300dpi
PRINTING WIDTH Up to 203.2mm
Connectivity
USB USB version 2.0 (Full speed) Type C
NFC Yes
Display & Memory
MEMORY CAPACITY RAM: 256MB, Flash: 64MB
Weight
WEIGHT 480 g
Operation
POWER SOURCE PA-BT-002 Rechargeable Li-ion Battery, PA-AD-600A AC Power adapter, PA-CD-600CG Car adapter (Cigarette socket type), PA-CD-600WR Car adapter (Permanent wired type) (Purchase separately).
TEMPERATURE - OPERATING
Rechargeable Li-ion battery, Car Adapter: -10°C to 50°C,
AC Power adapter: -10°C to 40°C
Product Specifications
Up to Print Speed 13.5ppm 3ips
Up to Resolution 300 x 300 dpi
100 Sheet Input Tray Capacity
256 MB Standard Memoroy
Power, Feed & Bluetooth Button
USB 2.0 Full Speed & Bluetooth
1 Year Return to Base Warranty
Brochure for Brother PJ-863 Bundle Pack A4 Mobile Thermal Printer
