Product Description
Print graphics, posters and fine art in high-definition with smart image processing. A 12-colour, 1.28" print head and LUCIA PRO pigment ink deliver a wide colour gamut and enhanced gradation, for incredible image clarity.
Printer Type
11-Color plus Chroma Optimizer 60-inch Printer
Number of Nozzles
Total: 18,432
All colors: 1,536 nozzles
Nozzle Pitch
600 dpi x 2
Non-firing nozzle detection and compensation
Print Resolution (Up to)
2400×1200dpi (Max)
OS Compatibility
32bit: Windows® (7/8.1/10)<
64bit: Windows 7, Windows 8.1, Windows 10Windows Server 2008R2, Windows Server 2012/2012R2Windows Server 2016, Windows Server 2019
Mac (OS 10.11.6), (Mac OS 10.12 – 10.15)
Standard Interfaces
USB 2.0 High-Speed
10/100/1000 Base-T/TX
Wireless LAN (IEEE 802.11 b/g/n)
USB Thumb Drive
Ink Droplet Size
minimum 4 picoliter
Ink Capacity
160, 330, or 700ml per color*
Ink Droplet Size
Pigment based LUCIA PRO Ink
Color Set
Photo Black, Matte Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Gray, Photo Gray, Red, Blue, +Chroma Optimizer
Hard Drive
500GB
Media Width
Cut Sheet - 6- 60
Roll Feed - 6 - 60
Media Thickness
Roll: 0.07 - 0.8 mm (2.8 - 31.5mil)
Maximum Roll Print Length
Roll Feed - 59' (18 meters)**
Maximum Media Roll Diameter
6.7 (170mm)
Borderless Printing Width
Custom roll width 6 – 60 with micro margin technology
Paper Feed Method
Roll Feed: Two Roll, Front-loading, Front Output
Manual Feed: Front-loading, Front Output
Languages
Swift Graphic Raster (SGRaster)
Noise Level Approx
Operation: 48 dB (A) or less
Accoustic Power: 6.6 Bels or less
Physical Dimensions
46.0 (H) x 78.7 (W) x 38.7 (D) (with basket open)
Weight
approx.368 lbs (roll holder included, no inks, no print heads)
Power Source
AC 100-240V(50-60Hz)
Power Consumption
Maximum: 97 W or less
Standby 2 W or less
Power Off: 0.3 W or less
Operating Environment
Temperature: 59 - 86°F
Relative Humidity: 10-80% (No Condensation)
User-replaceable items
Print Head (PF-10)
Maintenance Cartridge (MC-30)
Ink Tanks (PFI-1100/PFI-1300/PFI-1700)
Software Included
imagePROGRAF Printer Driver, Professional Print & Layout, Quick Utility Toolbox, Accounting Manager, Device Management Console, Media Configuration Tool, Printer Driver Extra Kit (Free Layout and Advanced Preview), Gallery Wrap Feature, Direct Print & Share4
What's in the box?
imagePROGRAF PRO-6100
Multifunction Roll Unit with Tools (Separate Box)
StandTools and Screws
AC Power Cable
Print Head PF-10
330ml Starter Ink Tanks (MBK/BK/C/M/Y/PC/PM/GY/PGY/R/B/CO)
2" Roll Holder with 3" Core Adapters
Quick Set-up Guide
Safety and Environmental Sheet
Setup Guide
Printer Stand Setup Guide
Print Head Alignment Sheet
USB Connection Sheet
Software Discs (Windows Drivers)
Sample media (5 sheets of Heavy Weight Coated HG paper A2 size)
Call Center Notice Card
User Registration Card
Printer and Print Head Warranty Cards
Media Compatibility Sheet
iWR Service Terms leaflet
Product Specifications
Max Printable Width 60"
Max Res 2400 x 1200 dpi
12 LUCIA PRO Inks
3GB Standard Memory
500GB Hard Drive
USB, Network & Wireless
One Year on site Warranty
