Product Description
Featuring a modern office design that compliments its environment and performance to match. Print multi-size jobs easily with auto switching between roll and tray. Enjoy high-speed printing as fast as 26 sec per A1/D plot. 1 GB memory.
Functions
Print
Print speed 26 sec/page on D, 81 D prints per hour[1]
Resolution (color) Up to 2400 x 1200 optimized dpi
Print Technology
HP Thermal Inkjet
Number of print cartridges 4 (C, M, Y, K)
Product disclaimer
This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. A reused HP chip enables the use of reused, remanufactured, and refilled cartridges. More at:
http://www.hp.com/learn/ds
Compatible ink types
Dye-based (C, M, Y); pigment-based (K)
Print languages
HP-GL/2, HP-RTL, CALS G4, JPEG, URF
Connectivity
Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct
Memory 1 GB
Hard disk None
Non-printable area (cut-sheet) 0.2 x 0.2 x 0.2 x 0.2 in
Line accuracy ±0.1%[3]
Maximum optical density (black)
8 L* min/2.10 D[4]
Finished output handling
Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
Media sizes supported
Auto sheet feeder: A4, A3; manual feed: A4, A3, A2, A1
Media sizes 11 to 24 in
Media types
Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene)
Roll external diameter 3.9 in
Media thickness Up to 11.8 mil
Power
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max. Not dual voltage, power supply varies by part number with # Option code identifier.
Power consumption
<35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (standby)
Operating temperature range
41 to 104ºF
Warranty
One-year limited hardware warranty
Software included
HP Click, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant
Dimensions (W X D X H)
39.9 x 21.9 x 36.7 in
Weight 74.1 lb
Package weight 94.8 lb
What's in the box
HP DesignJet Studio 24-in Printer, printer stand, automatic sheet feeder, roll cover, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord
Product Specifications
Up to Print Speed 26Sec.
Up to Res 2400 x 1200 dpi
1GB Standard Memory
Automatic sheet feeder
1376 Printhead Nozzles
USB, Network & Wireless
One Year Limited Warranty
