Specifications are provided for reference and are based on printer tests using Zebra brand supplies. Results may vary in actual application settings or when using other than recommended Zebra supplies. Zebra recommends always qualifying any application with thorough testing.
Features
8 ips maximum print speed
ZPL II® and EPL2™ programming languages
Connectivity: Ethernet, USB 2.0, USB Host
4.3 in. full-color touch LCD (480 × 272 resolution), 5 status icons, 3 button user interface
Tested for robust tolerance to temperature, humidity, dust and other tough environmental challenges
Standard on thermal transfer models
Printer setup mobile app for Android™ and iOS via Bluetooth® Low Energy 5 (BLE) connection
BLE is best used for printer setup and light data transfer events. For best performance when printing, use a printer with Bluetooth Classic.
Technical Specs
Cutter
Cutter Yes
Memory
Standard Memory 256 MB
Power Description
Power Source AC Supply
Software
Operating System Supported
Link-OS
Warranty
Limited Warranty 2 Year
Environmental Conditions
Operating Temperature 4.4°C - 40.6°C
Operating Relative Humidity 10% - 90%
Interfaces/Ports
USB Yes
USB Host Yes
Technical Information
Application/Usage Desktop
Barcode Symbology Supported Interleaved 2 of 5
MSI-3
EAN-8
Code 39
UPC-A
UPC-E
RSS-14
PDF417
UCC/EAN 128
Data Matrix
EAN-13 With 2 and 5 Digit Extension
Macro PDF-417
Plessey
Maxi Code
German Post Code
POSTNET
UPC-A with 2 and 5 Add-on
EAN-8 With 2 or 5 Digit Extension
Codabar
Micro PDF-417
UPC-E with EAN 2 or 5 Digit Extension
EAN-13
Code 93
Code 128 (A/B/C)
Maximum Print Width 54 mm (2.13")
Recommended Use Label Print
Connectivity Technology Wired
Features Compact
LCD Display
Maximum Mono Print Speed 152 mm/s
Print Color Capability Monochrome
Maximum Print Length 991 mm
Optional Connectivity Serial (RS-232)
Wireless LAN
Real Time Clock Yes
Maximum Print Resolution (dpi) 300
Display & Graphics
Display Screen Yes
Screen Size 10.9 cm (4.3")
Display Screen Type LCD
Network & Communication
Bluetooth Yes
Ethernet Yes
Ethernet Technology Fast Ethernet
Physical Characteristics
Weight (Approximate) 1.63 kg
Height 169.2 mm
Width 138.7 mm
Depth 242.9 mm
Fonts & Emulation
Language Emulation EPL2
EZPL
XML
ZPL II
ZPL
General Information
Product Type Thermal Transfer Printer
Manufacturer Part Number ZD6A123-T2PE00EZ
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZD611
Product Name ZD611 Thermal Transfer Printer
Brand Name Zebra
Miscellaneous
Platform Supported PC
Android
iOS
Energy Star Yes
Power Cable Localization UK
EU
JP
AUS
Media Types & Handling
Media Thickness 190.5 µm
Maximum Roll Diameter 127 mm
Media Type Tag Stock
Fanfold
Wristband
Linerless
Continuous Receipt
Notch
Die-cut Label
Label
Gap
Roll Fed
Continuous Label
Media Sensor Label Taken Sensor
Maximum Label Width 59.94 mm
Maximum Label Length 39 mm
