Product Description
EXCEPTIONAL DURABILITY AND RELIABILITY FOR THE TOUGHEST ENVIRONMENTS
Zebra's ZQ500™ Series just got tougher. The premium ZQ511™ and ZQ521™ printers - both available in RFID models - give you best-in-class, rugged mobile printing for applications in any industry. Experience ultimate durability. Engineered for tough, demanding indoor and outdoor conditions, these printers can withstand significant drops, tumbles, accidents, and environmental extremes that are common in mobile workplaces. Additional features, enhanced durability, and military-grade design mean this printer will work as hard as you do.
TOUGH. RELIABLE. BUILT TO ENDURE.
The Most Rugged Printers on the Market
You need a mobile printer that can handle serious abuse. Designed and certified to meet MIL-STD 810G for drop and shock, and tumble tested per the IEC68-2-32 spec to handle 1300 tumbles from 3.3' (1M), the ZQ511 and ZQ521 printers can withstand more than the average mobile printer.
Protection from solid and liquid ingress is no problem with an IP54 rating right out of the box without the need for a protective case.
If this isn't enough to convince you that these are ultra-rugged mobile printers, we also offer an optional exoskeleton case that increases our standard drop testing from 6.6' to 10' and improves the IP rating to IP65.
Built to Last
New over-molding helps increase longevity and keeps your ZQ500 Series looking good over the life of the printer.
PRINT IT ALL: RECEIPTS, RFID TAGS, LABELS, AND LINERLESS
Optimized for on-demand receipt printing in 3" (72mm) and 4" (104mm) print widths, the ZQ511 and ZQ521 printers also print a variety of labels including UHF RFID tags for all your tracking needs. Zebra's comprehensive RFID portfolio is the only one to include mobile printers to help you reduce errors, and print and encodes RFID labels on the go.
ON-THE-GO POWER, FUNCTIONALITY, AND PREMIUM PERFORMANCE
Get All the Benefits of Linerless Media
Eliminate waste and improve your company's green initiative with linerless printing. Linerless media also allows your workforce to spend less time disposing waste and more time on the task at hand - improving your workforce productivity. And, since there are more labels on a roll, there are fewer rolls of media to carry and fewer media roll changes.
Optimize Your Printing Quality and Power
Consistent outstanding print quality and performance are key. A new printhead and print mechanism, as well as a new processor and added memory, deliver it. Keep your employees on task and on schedule with the ZQ500 Series' secondary Bluetooth communication channel. Send print jobs to the printer via one channel, while a second channel performs additional functions such as device management.
Boost print speeds (5+ inches per minute) with the "draft mode" feature for text-only printing. Do more on a single battery charge with Zebra's patented Power Smart Print Technology™ that delivers the exact amount of power required for the highest quality printing. And, experience consistently sharp print quality-even in hot and cold temperatures with enhanced temperature compensation.
Power Your Team to Do More
The ZQ511 and ZQ521 printers' high-capacity 3250 mAh PowerPrecision+ battery powers your team - even during the longest shift. The printer also conserves battery life by entering sleep mode when not in use, then automatically wakes up when a print job is sent.
Features
Android, Apple iOS, and Windows Mobile connectivity
Bluetooth specification 4.1 EDR + LE
WLAN 802.11ac
Fast roaming 802.11r supported
528 MHz ARM processor
3250 mAh PowerPrecision+ (retrievable, rechargeable Li-Ion)
USB On-The-Go ports (with optional strain relief)
Power Smart Print Technology - anticipates upcoming printing to optimize battery consumption and print speed
Direct thermal printing of barcodes, text, and graphics
IP54 rated for protection against solid and liquid ingress
Technical Specs
Interfaces/Ports
USB Yes
Memory
Standard Memory 512 MB
Software
Operating System Supported
Link-OS® printer operating system
Warranty
Limited Warranty 2 Year
Technical Information
Application/Usage Mobile
Barcode Symbology Supported Data Matrix
PDF417
Codabar (NW-7)
Code 128
2 and 5 Digits Add-on
LOGMARS
UPC-A
Maxi Code
AZTEC
UPC-E
MSI PLESSEY
Interleaved 2 of 5
QR Code
Codablock
Code 49
UCC/EAN 128
GS1 DataBar
Plessey
Standard 2 of 5
Codabar
Micro PDF-417
Code 39
POSTNET
MSI
EAN-8
ISBT-128
Planet Code
Code 93
Industrial 2 of 5
TLC 39
EAN-13
FIM
UPC-E with EAN 2 or 5-Digit Extension
Code 11
Maximum Print Width 72 mm (2.83")
Recommended Use Receipt Print
Connectivity Technology Wireless
Features Drop Resistant
Rugged
Maximum Mono Print Speed 127 mm/s
Print Color Capability Monochrome
Maximum Print Length 990.60 mm
International Protection (IP) code IP54
Fonts Included Contains UFST® from Agfa Monotype Corporation)
25 bitmapped
1 smooth
scalable (CG Triumvirate Bold Condensed
Maximum Print Resolution (dpi) 203
Battery Information
Battery Capacity 3250 mAh
Battery Included Yes
Display & Graphics
Display Screen Yes
Display Screen Type LCD
Power Description
Input Voltage 24 V DC
12 V DC
Power Source Battery
Environmental Conditions
Storage Relative Humidity 10% - 90%
Storage Temperature -30°C - 65.6°C
Operating Temperature -20°C - 55°C
Operating Relative Humidity -10% - 90%
Fonts & Emulation
Language Emulation XML
ZBI
ZPL
ESC/POS
CPCL
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
RFID Yes
Near Field Communication (NFC) Yes
Physical Characteristics
Weight (Approximate) 630 g
Form Factor Handheld
Height 61 mm
Width 119.4 mm
Depth 149.9 mm
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ51-BAW000A-00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ511
Product Name ZQ511 Direct Thermal Printer
Product Series ZQ500
Brand Name Zebra
Media Types & Handling
Media Thickness 139.7 µm
Maximum Roll Diameter 51 mm
Media Type Black Mark
Receipt
Gap
Linerless
Tag
Maximum Label Width 80.01 mm
Miscellaneous
Platform Supported PC
Android
iOS
Power Cable Localization MY
LK
NZ
TW
AUS
India
KR
ID
