Product Description
Easily reduce the risk of errors in specimen collection with premium mobile printing at the point of care
Want to improve specimen labeling accuracy, staff productivity, and patient safety? With the ZQ600/ZQ600 Plus Healthcare Series, you can. The ZQ600/ZQ600 Plus takes Zebra's popular QLn platform and makes it even better-adding advanced technology and innovative design that drive productivity, ease of use, and manageability to a new level. Designed specifically for healthcare, these compact printers are built to withstand constant disinfecting. The color display takes all the guesswork out of printer status. Advanced battery technology powers every minute of the longest shift. The ZQ600/ZQ600 Plus offers the fastest, most dependable wireless connections inside the four walls and your IT department will find the ZQ600/ZQ600 Plus easier to integrate, manage, and secure. The ZQ600 Plus Series delivers the same features and specifications as the ZQ600 Series, using redesigned electronics for long-term product continuity and availability. The ZQ600 Plus printers require new, different firmware and drivers.
The Latest Wireless Connections for Fast and Secure Printing
The ZQ600/ZQ600 Plus Series offers the fastest, most dependable wireless connections inside the four walls. With support for 802.11ac Wi-Fi and its latest security protocols, plus Bluetooth® Classic and Low Energy (BLE), healthcare staff can count on blazing fast and secure connections.
Industry-Standard 802.11r Fast Roaming for Seamless Access
Support for 802.11r fast roaming technology delivers the dependable wireless connection your on-the-move staff needs.
Instant Wake-Up Over Wi-Fi
Every second counts in the mission-critical world of healthcare- that's why the ZQ600/ZQ600 Plus offers instant wake on Wi-Fi. This intelligent printer enters sleep mode when it is idle, and automatically wakes up the moment a user sends a print job, delivering instant availability along with maximum battery cycle time. And the ZQ600/ZQ600 Plus' instant wake-up works over both Wi-Fi and Bluetooth.
Large Color Display Makes Configuration and Operation a Snap
It's easy to set up and maintain the ZQ600/ZQ600 Plus Series with its large display, user-friendly interface and easily customized menu. The display changes color when the printer is paused or in an error state, such as out of media or latch open, so users instantly know what the printer needs to stay up and running. And since the ZQ600/ZQ600 Plus Series is based on Zebra's Link-OS menu system, you'll get a common UI and user experience across other Zebra Link-OS mobile, desktop, and industrial printers to lower the learning curve.
Business Tough-Built for All-Day Everyday Use
While the ZQ600/ZQ600 Plus is lightweight and comfortable to wear all shift long, it is loaded with features that give it long-lasting durability, including over-molding, a tempered-glass display and seamless one-piece design. The high-grade resin is one of the toughest plastics available for greater impact resistance. And multiple mechanical design improvements further increase printer robustness and uptime.
Features
Apple® iOS, Android™ and Windows® Mobile connectivity
Direct thermal printing of barcodes, text, and graphics
CPCL, EPL™ and ZPL® programming languages
512 MB Flash supports downloadable programs, receipt formats, fonts, and graphics (128 MB available for user storage)
Built-in battery charger
Belt clip for unobtrusive and convenient printing
Black mark and gap media sensing using fixed center position sensors
Easy-to-use peel and present mode
Label present sensor for issuing labels one at a time
Tear bar for easy media dispensing
Technical Specs
Battery Information
Battery Capacity 3250 mAh
Display & Graphics
Display Screen Yes
Memory
Standard Memory 256 MB
Technical Information
Application/Usage Industrial
Mobile
Desktop
Barcode Symbology Supported MSI PLESSEY
EAN-8
GS1 DataBar
FIM
Data Matrix
UCC/EAN 128
2 and 5 Digits Add-on
Code 128
AZTEC
Micro PDF-417
TLC 39
POSTNET
QR Code
PDF417
Maxi Code
UPC-A
UPC E with 2 and 5 add on
Codabar (NW-7)
Code 93
EAN-13
Interleaved 2 of 5
Code 39
Maximum Print Width 72 mm (2.83")
Recommended Use Label/Receipt Print
Features Shoulder Strap
Dust Resistant
Belt Clip
Water Resistant
Maximum Mono Print Speed 115 mm/s
Mobile Device Printing Yes
Print Color Capability Monochrome
Maximum Print Length 813 mm
Character Sets Universal Font Scaling Technology (UFST)
Agfa Monotype
Optional Connectivity USB
Serial (RS-232)
Ethernet
Ingress Protection (IP) Rating IP54
Maximum Print Resolution (dpi) 203
Power Description
Power Source Battery
Software
Operating System Supported Link-OS
Warranty
Limited Warranty 1 Year
Environmental Conditions
Storage Relative Humidity 10% - 90%
Storage Temperature -25°C - 65°C
Operating Temperature 0°C - 50°C
Operating Relative Humidity 10% - 90%
Fonts & Emulation
Language Emulation ZBI 2.0
EPL
ZPL
CPCL
Miscellaneous
Platform Supported PC
iOS
Android
Certifications & Standards
Emissions:
FCC Part 15
Subpart B
EN55022 Class-B
EN60950
EN55024
VCCI class B
Susceptibility:
EN55024
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
Safety:
CE
TUV
CSA
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Near Field Communication (NFC) Yes
Physical Characteristics
Weight (Approximate) 730 g
Height 77 mm
Width 117.9 mm
Depth 173.7 mm
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ62-HAWAA04-00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ620 Plus-HC
Product Name ZQ620 Plus-HC Direct Thermal Printer
Product Series ZQ600
Brand Name Zebra
Media Types & Handling
Media Thickness 165.1 µm
Maximum Roll Diameter 66.04 mm
Media Type Die-cut Label
Black Mark
Black Bar
Label
Gap
Tag
Receipt
Linered Media
Media Sensor Gap Sensor
Black Mark Sensor
Maximum Label Width 79.38 mm
Maximum Label Length 812.80 mm
